(888) 312-8812 Login SignupACDELCO 18A730 Disc Brake Rotor - 5 Lug Holes, Cast Iron, Plain, Turned Ground, Vented, Front
Tap to view 2 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
ACDELCO 18A730 Part Description
Gold™ Disc Brake Rotor - Front, Vented
ACDELCO 18A730 Specifications
Product Attributes
| Nominal Thickness | 24.13mm (0.95 in.) |
| Center Hole Diameter | 60.96mm (2.4 in.) |
| BOLT CIRCLE | 99.06mm (3.9 in.) |
| Lug Holes Quantity | 5 |
| Lug Holes Quantity | 5 |
| Minimum Thickness | 22.352mm (0.88 in.) |
| Minimum Thickness | 22.352mm (0.88 in.) |
| Quantity | 1 Per Pack |
| Quantity | 1 Per Pack |
| Rotor Construction | 1-Piece |
| Rotor Construction | 1-Piece |
| Rotor Design | Rotors Only |
| Rotor Design | Rotors Only |
| Rotor Diameter | 256.54mm (10.1 in.) |
| Rotor Diameter | 256.54mm (10.1 in.) |
| Rotor Finish | Turned Ground |
| Rotor Finish | Turned Ground |
| Rotor Height | 38.1mm (1.5 in.) |
| Rotor Height | 38.1mm (1.5 in.) |
| Rotor Material | Cast Iron |
| Rotor Material | Cast Iron |
| Rotor Style | Plain |
| Rotor type | Vented |
| Rotor type | Vented |
| Mounting Bolt Hole Circle Diameter | 3.93 IN |
| Nominal Thickness | 0.945 IN |
| Height (in) | 1.5 in |
| Pad Contact Surface Width | 2 IN |
| Center Bore Diameter (in) | 2.4in |
| Bolt Circle Diameter (in) | 3.9 in |
| Bolt Hole Quantity | 5 |
| Mounting Bolt Hole Diameter | 13.9 MM |
| Mounting Bolt Hole Circle Diameter | 99.8 MM |
| Mounting Bolt Hole Diameter | 0.548 IN |
| Height (mm) | 38.1 mm |
| Pad Contact Surface Width | 50.15 MM |
| Center Bore Diameter (mm) | 61mm |
| Bolt Circle Diameter (mm) | 100 mm |
| Outside Diameter | 256.3 MM |
| Overall Rotor Diameter (mm) | 256.29mm |
| Discard Thickness | 22.35 MM |
| Product Description | ACDelco Gold (Professional) Black Hat Disc Brake Rotors are a high quality alternative to Original Equipment (OE) parts. ACDelco Gold (Professional) parts are manufactured to meet your expectations for fit, form, and function, making them a smart choice for General Motors vehicles, as well as most makes and models, including special applications. These high-quality parts are backed by General Motors. Some ACDelco Gold parts may have formerly appeared as ACDelco Professional. ⚠<b> WARNING:</b> Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Material | Cast Iron |
| Construction | Full Cast |
| Disc Finish | Ground |
| Features & Benefits - Bullet 3 | Manufactured to meet specifications for fit, form, and function for General Motors vehicles as well as most makes and models |
| Programming Required | No |
| Slotted | No |
| Features & Benefits - Bullet 2 | Premium aftermarket replacement part |
| Grade Type | Regular |
| Surface Type | Smooth |
| Features & Benefits - Bullet 1 | Some ACDelco Gold parts may have formerly appeared as ACDelco Professional |
| Hat Finish | Turned |
| Solid Or Vented Type Rotor | Vented |
| Rust Resistant Coating | Yes |
| Discard Thickness | 0.88 IN |
| Center Hole Diameter | 60.95 MM |
| Center Hole Diameter | 2.4 IN |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 24 MM |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Overall Height | 1.5 IN |
| Overall Height | 38.1 MM |
| Stud/Lug Hole Quantity | 5 |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Outside Diameter | 10.09 IN |
| ABS Tone Ring Included | No |
Additional Information
| Warranty Special | 24 Months/Unlimited Miles Limited Warranty (Parts Only). Please see ACDelco.com for more details|36 Months/60,000 Kilometers Limited Warranty (Parts Only). Please see ACDelcocanada.com for more details |
| Harmonized Tariff Code (HTS) | 8708305030 |
| Country of Origin (Primary) | CN |
| Warranty Special UOM | TX |
| UPC | 00707773313145 |
ACDELCO 18A730 Cross References
ACDELCO 18A730 Fits Vehicles
- Plymouth Grand Voyager (1996-2000)
- Chrysler Grand Voyager (2000)
- Chrysler Town & Country (1996-2000)
- Plymouth Voyager (1996-2000)
- Dodge Caravan (1996-2000)
- Chrysler Voyager (2000)
- Dodge Grand Caravan (1996-2000)
