RAYBESTOS 680958R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2012 Ford Fusion Rear, 2012 Lincoln MKZ Rear
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 680958R Specifications
Product Attributes
| Center Hole Diameter | 2.83 IN |
| Center Hole Diameter | 71.9 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.315 IN |
| Discard Thickness | 8 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 7.48 IN |
| Inside Diameter | 190 MM |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 0.507 IN |
| Mounting Bolt Hole Diameter | 12.9 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.429 IN |
| Nominal Thickness | 10.9 MM |
| Outside Diameter | 11.024 IN |
| Outside Diameter | 280 MM |
| Overall Height | 1.6 IN |
| Overall Height | 40.65 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213028324 |
RAYBESTOS 680958R Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH317199 |
| AutoZone | 31325DL |
| BRAKEBEST | 680958, 680958FZN, 680958R, 680958RGS |
| Brembo | 08.N226.11 |
| CENTRIC | 121.45064 |
| DURA CORP | BR54185 |
| FORD | 9E5Z2C026B |
| MAGMA PRODUCTS | PMR203087 |
| NEWTEK AUTOMOTIVE | 54185 |
| Newtek Automotive USA | 54185 |
| PROMAX | 14-54185 |
| TopNotch | TN680958GEO |
| UAP | R61097 |
| WAGNER BRAKE | BD180397, BD180397E |
| WORLDPARTS | WS1-154185 |
RAYBESTOS 680958R Fits Vehicles
- Lincoln MKZ (2012)
- Ford Fusion (2012)
