MOOG ES2764L Part Description
Manufacturer
Product Description
Steering Tie Rod End
Application Summary
1985-1986 BMW 524td (Left Outer, Right Inner) (Qualifier: with Left Hand Threads); 1989-1995 BMW 525i (Left Outer, Right Inner) (Qualifier: with Left Hand Threads); 1982-1988 BMW 528e (Left Outer, Right Inner) (Qualifier: with Left Hand Threads); 1994-1995 BMW 530i (Left Outer, Right Inner) (Qualifier: with Left Hand Threads); 1983-1984 BMW 533i (Right Inner, Left Outer) (Qualifier: with Left Hand Threads); 1985-1993 BMW 535i (Left Outer, Right Inner) (Qualifier: with Left Hand Threads); 1988 BMW 535is (Right Inner, Left Outer) (Qualifier: with Left Hand Threads); 1994-1995 BMW 540i (Left Outer, Right Inner) (Qualifier: with Left Hand Threads); 1983-1984 BMW 633CSi (Right Inner, Left Outer) (Qualifier: with Left Hand Threads); 1985-1989 BMW 635CSi (Left Outer, Right Inner) (Qualifier: with Left Hand Threads); 1987-1992 BMW 735i (Right Inner, Left Outer) (Mfr Body Code: E32 / Qualifier: with Left Hand Threads); 1988-1992 BMW 735iL (Left Outer, Right Inner) (Qualifier: with Left Hand Threads); 1993-1994 BMW 740i (Left Outer, Right Inner) (Qualifier: with Left Hand Threads); 1993-1994 BMW 740iL (Right Inner, Left Outer) (Qualifier: with Left Hand Threads); 1988-1994 BMW 750iL (Right Inner, Left Outer) (Qualifier: with Left Hand Threads); 1994-1997 BMW 840Ci (Left Outer, Right Inner) (Qualifier: with Left Hand Threads); 1993-1997 BMW 850Ci (Left Outer, Right Inner) (Qualifier: with Left Hand Threads); 1994-1995 BMW 850CSi (Left Outer, Right Inner) (Qualifier: with Left Hand Threads); 1991-1992 BMW 850i (Right Inner, Left Outer) (Qualifier: with Left Hand Threads); 1988-1993 BMW M5 (Left Outer, Right Inner) (Qualifier: with Left Hand Threads); 1987-1988 BMW M6 (Left Outer, Right Inner) (Qualifier: with Left Hand Threads); 1993 BMW 525iT (Right Inner, Left Outer) (Qualifier: with Left Hand Threads)
Features & Benefits
- Designed for OE fit and function
- Premium boot keeps out contaminants
- Made of forged alloy steel for durability
- Replacement helps restore vehicle handling
Passenger Car/Light Truck Applications
| Make | Model | Year |
|---|---|---|
| BMW | 524TD | 1986-1985 |
| 525I | 1995-1989 | |
| 525IT | 1995-1993 | |
| 528E | 1988-1982 | |
| 530I | 1995-1994 | |
| 530IT | 1995-1994 | |
| 533I | 1984-1983 | |
| 535I | 1993-1985 | |
| 540I | 1995-1994 | |
| 633CSI | 1984-1983 | |
| 635CSI | 1989-1985 | |
| 735I | 1992-1987 | |
| 735IL | 1992-1988 | |
| 740I | 1994-1993 | |
| 740IL | 1994-1993 | |
| 750IL | 1994-1988 | |
| 840CI | 1996-1994 | |
| 850CI | 1997-1993 | |
| 850CSI | 1995-1994 | |
| 850I | 1992-1991 | |
| M5 | 1993-1988 | |
| M6 | 1988-1987 |
MOOG ES2764L Specifications
Product Attributes
| End 1 Gender | Male |
| End 2 Gender | Male |
| Type | Straight |
| End 2 Thread Diameter | 10.0 MM |
| End 1 Thread Direction | Counterclockwise |
| End 2 Thread Pitch | 1.0 MM |
| End 1 Thread Pitch | 1.5 MM |
| Length - Stud Center to End | 3.190 IN |
| End 1 Thread Diameter | 14.0 MM |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708947550 |
| Harmonized Tariff Code (HTS) | 8708947550 |
| UPC | 00080066031484 |
| VMRS Code | 015004019 |
| UNSPSC | 25174205 |
MOOG ES2764L Cross References
| Brand | Part Number |
|---|---|
| 080066166469 | |
| ACDelco | 45A0503, 46A0503A |
| Autospecialty | 03-04009, 304009 |
| BMW | 32211127918, 32211130001, 32211135819 |
| BREMI | 11346 |
| Beck/Arnley | 101-3767, 101-4124 |
| Centric Parts | 612.34003 |
| DELPHI | TA1153 |
| DORMAN | T2764, T2764PR |
| Dorman | 534419 |
| Duralast | ES2764L |
| Firestone | ES2764L |
| ITM Engine Components | 40-02322, 40-02328, 40-02329 |
| Lazorlite | U85-3550 |
| MAS Industries | T2764, TA14025 |
| MEYLE | 316 020 4216 |
| Mcquay-Norris | ES2764L |
| Mevotech | MES2764L, PES2764L |
| NAPA | ES2762A, 269-2815 |
| Perfect Circle | 269-2815 |
| Raybestos Brakes | 401-1503B, 401-1503 |
| SUSPENSIA | X05TE0955 |
| Sealed Power | 802-2764L |
| TRW | ES2764L |
| TRW Steering and Suspension Parts | JTE101, ES2762A, ES2764, ES2764L |
| URO | 32211135819 |
| VAICO | V20-7052 |
MOOG ES2764L Fits Vehicles
- BMW 525iT (1993)
- BMW M6 (1987-1988)
- BMW M5 (1988, 1991-1993)
- BMW 850i (1991-1992)
- BMW 850CSi (1994-1995)
- BMW 850Ci (1993-1997)
- BMW 840Ci (1994-1997)
- BMW 750iL (1988-1994)
- BMW 740iL (1993-1994)
- BMW 740i (1993-1994)
- BMW 735iL (1988-1992)
- BMW 735i (1987-1992)
- BMW 635CSi (1985-1989)
- BMW 633CSi (1983-1984)
- BMW 535is (1988)
- BMW 540i (1994-1995)
- BMW 535i (1985-1993)
- BMW 533i (1983-1984)
- BMW 530i (1994-1995)
- BMW 528e (1982-1988)
- BMW 525i (1989-1995)
- BMW 524td (1985-1986)
MOOG ES2764L Customer Reviews
No reviews yet
Be the first to review this product!
MOOG ES2764L Manufacturer Information
For over 100 years, Moog® has been an industry leader in mid- to high-end aftermarket parts for steering, suspension, and driveline systems worldwide. Utilized by daily commuters to entire fleets, Moog parts have become synonymous with reliable performance that’s just as good or even better than their OE counterparts. Moog also incorporates innovative features in their products not found in competing products, such as patented forged steel bodies and metal “gusher” bearings that greatly reduce friction across moving components. The brand also leads the way in after-sales support, with comprehensive technical assistance and training materials available for customers around the world.
