MOOG ES2158R Part Description
Manufacturer
Product Description
Tie Rod End
Application Summary
BMW: 320i (1977-1983); Porsche: 911 (1981-1984), 911 Turbo Carrera {Type 930} (1976-1977), 930 Turbo (1978-1979)
Features & Benefits
- Loose or worn chassis parts can lead to premature tire wear
- Exclusive cover plate protects against contaminants leaking into the bearing surface
- Greaseable socket design allows new lubricant to flush contaminants from the assembly, reducing corrosion and wear
- Patented cover plate design allows for tighter tolerances vs traditional designs for a more durable part
- Powdered metal gusher bearing design enables grease to flow through bearing to stud for reduced friction and enhanced strength
Moog Front Steering, Outer Tie Rod End - Direct OE replacement -MOOG TIE ROD END, OUTER, SOLD INDIVIDUALLY -- A High Quality Direct Fit OEM Replacement Tie Rod End, Designed To Consistently Produce Just The Right Amount Of Preload To Provide Proper Steering Effort, Housing Is Forged Then Heat-Treated For Strength And Durability, Sealed With A Premium Polychloroprene To Keep Out Dirt, Its Bearings Include Grease Grooves That Ensure Flow Of Lubrication Throughout The PartFront Steering, Outer
MOOG ES2158R Specifications
Product Attributes
| End 1 Gender | Female |
| End 2 Gender | Female |
| Type | Straight |
| End 2 Thread Diameter | 10.0 MM |
| End 1 Thread Direction | Clockwise |
| End 2 Thread Pitch | 1.2 MM |
| End 1 Thread Pitch | 1.5 MM |
| Length - Stud Center to End | 2.870 IN |
| End 1 Thread Diameter | 14.0 MM |
Additional Information
| Country of Origin (Primary) | DE |
| Harmonized Tariff Code (Schedule B) | 8708947550 |
| Harmonized Tariff Code (HTS) | 8708947550 |
| Remanufactured Part | N |
| UPC | 00080066143163 |
MOOG ES2158R Cross References
| Brand | Part Number |
|---|---|
| 080066143163 | |
| ACDelco | 45A0285 |
| Autospecialty | 03-04004, 304004, 304501, 304502 |
| BMW | 32111116463, 32-21-1-116-463, 32111115241, 32111115229, 32111115239 |
| Beck/Arnley | 101-3093, 101-4031, 101-4032 |
| CEW | 4931000 |
| Centric Parts | 612.37030 |
| DELPHI | TA770, TA5011 |
| DORMAN | T2158, T2158PR |
| Dorman | 534-327 |
| Duralast | ES2158R |
| Lazorlite | U85-2821 |
| MAS Industries | T2158 |
| MEYLE | 1160203226 |
| Mcquay-Norris | ES2158R |
| Mevotech | MES2158R, PES2158R |
| Midas | TR1551 |
| NAPA | 269-2567 |
| Perfect Circle | 269-2567 |
| Porsche | 93034732200 |
| Raybestos Brakes | 401-1285 |
| SUSPENSIA | X05TE0851 |
| Sealed Power | 802-2158R |
| TRW | ES2158R |
| TRW Steering and Suspension Parts | ES2158R |
| VAICO | V20-9506 |
| Vera | 60-01662 |
| Volkswagen | 93034732200 |
