(888) 312-8812 Login SignupMONROE MA769 Max-Air Air Adjustable Air Shock Absorber Pack of 2
Tap to view 3 more
MSRP: $187.24
$11599
Save $71.25
Limited availability at this price!
In Stock
Get it by Thursday, Feb 19
MONROE MA769 Part Description
Manufacturer
Product Description
Max-Air Air Adjustable Air Shock Absorber Pack of 2
Features & Benefits
- MAINTAIN RIDE HEIGHT UNDER LOAD -- Air chamber can be inflated or deflated up to 150 PSI to maintain level height with additional weight up to 1,200 lbs. (capacity is limited by suspension, tires and transmission; see owner's manual)
- EASY TO ADJUST -- Special air fitting resists air leakage and ties into factory system (where applicable) or manually inflates with an air compressor; pair with Monroe air shock accessory and shock air hose AK kits (varies by application)
- EXCEPTIONAL HANDLING -- Full-displaced valving on compression and extension cycles for a smooth ride
- BUILT TO LAST -- Hardened and precision ground piston rod for consistent performance, sintered iron piston for enhanced durability and longer service life and lubricated air sleeve reduces friction for smooth operation
- CONSISTENT RIDE -- OE all-weather fluid contains special modifiers to handle extreme temperatures and help reduce friction and ensure smooth rod reaction
MONROE MA769 Specifications
Product Attributes
| Compressed Length | 14.125 IN |
| Extended Length | 22.875 in |
| Travel Length | 8.75 in |
| Lower Mount Code | LS26 |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 1.1/2" Sleeve OAL |
| Upper Mount Code | L1 |
| Upper Mount Type | Loop Bushing Mount - 5/8" Bushing ID X 1.5/16" Bushing OAL |
| Dust Shield Included | Yes |
| Dust Shield Material | Rubber |
| Includes Bump Stop | Yes |
| Hydraulic Lockout | No |
| Parts Pack(s) | (2) P00827 |
| Part Description | Air Shock Absorber |
| Internal Rebound Bumper | Yes |
| Compressed Length | 358.8 MM |
| Extended Length | 581 MM |
| Travel Length | 222.3 MM |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Boot Included | Yes |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Grade Type | Premium |
Additional Information
| MSDS Sheet Number | 01164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598031426 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE MA769 Cross References
MONROE MA769 Fits Vehicles
- Mazda B4000 (1994-2004)
- Mazda B3000 (1994-2007)
- Mazda B2500 (1998-2001)
- Mazda B2300 (1994-1997, 2001-2009)
- Ford Ranger (1983-2011)
- Ford Bronco II (1984-1990)
