MONROE 911536 Reflex Suspension Shock Absorber

911536 by MONROE - Reflex Suspension Shock Absorber
MONROE
Tap to view 5 more

MSRP: $131.98

$70.99

Save $60.99

Limited availability at this price!

In Stock

Get it by Monday, Jan 12
No Hassle Return Policy Details
Free Economy shipping on orders over $499 details
Orders placed before 2pm EST will ship same day

MONROE 911536 Part Description

Manufacturer

MONROE

Product Description

Reflex Suspension Shock Absorber

Features & Benefits

  • MAINTAINS VEHICLE CONTROL -- Monotube technology maintains vehicle control over bumps, dips and potholes for vehicles originally equipped with monotube shocks and struts
  • IMPROVED IMPACT ABSORPTION -- Hydraulic lock-out isolates suspension impact and helps maintain vehicle integrity (where applicable)
  • CONSISTENT RIDE -- High temperature OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
  • EXCELLENT RESPONSE AND STABILITY -- High-pressure nitrogen charge provides a quicker response for excellent vehicle control
  • BUILT TO LAST -- High-strength shock housing and hardened, chrome-plated piston rod provide durability and longer service life
  • CONTROL AND DURABILITY -- Fluon-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
  • REDUCED SHOCK FADE AND AERATION -- Free floating dividing piston separates shock fluid from high-pressure gas charged to reduce shock fade and aeration
  • BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee

MONROE 911536 Specifications

Product Attributes

Lower Mount Code LS26
Upper Mount Code S4
Dust Shield Included Yes
Includes Bump Stop No
Internal Rebound Bumper No
Hydraulic Lockout No
Part Description Shock Absorber
Compressed Length 14.02 IN
Dust Shield Material Rubber
Extended Length 21.93 in
Gas Charged Yes
Lower Mount Type Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 1.1/2" Sleeve OAL
Parts Pack(s) P01136
Travel Length 7.91 in
Upper Mount Type Stem Mount - 2.3/8" Stem Length X 3/8"-16 Thread Pitch
Compressed Length 356.1 MM
Extended Length 557 MM
Travel Length 200.9 MM
Shock Absorber Rod End Measuring Point Base of Stem
Shock Absorber Body End Measuring Point Center of Loop

Additional Information

MSDS Sheet Number 1164
Country of Origin (Primary) MX
Canadian Harmonizing Tariff Code 8708803000
Harmonized Tariff Code (Schedule B) 8708801600
Harmonized Tariff Code (HTS) 8708801600
UPC 00048598098771
VMRS Code 016008003
UNSPSC 25172011

MONROE 911536 Part Interchanges

Brand Part Number
Jeep 52126811AB, 68003290AC, 68003291AC, 68003292AC, 68003293AC, 68003303AC, 68003303AE, 68003304AC, 68003305AC, 68003306AB, 68003307AB, 68003308AB, 68003308AC, 68003309AB, 68003311AB, 68003313AB, 68027792AA, 68027793AA, 68027794AA, 68027794AB, 68027794AC, 68027795AA, 68027796AA, 68027797AA, 68027799AA, 68027799AB, 68028415AC, 68029954AA, 68029955AA, 68029959AA, 68029960AA, 68029961AA, 68032197AA, 68047812AA, 68047812AB, 68047812AC, 68047812AD, 68047814AA, 68047814AB, 68067515AA, 68067515AC, 68067515AD, 68067516AA, 68067516AC, 68067516AE, 68067516AF, 68087359AA, 68087359AB, 68087359AC, 68087359AE, 68087359AF, 68087360AA, 68087360AB, 68087360AC, 68087360AD, 68087360AE, 68087362AA, 68087362AC, 68087362AD, 68087363AA, 68087363AB, 68087363AC, 68138775AA, 68138775AB, 68138775AC, 68138853AA, 68138853AB
OEM 68003292AC, 68029954AA, 68027799AA, 68138775AC, 68087360AE, 68047812AC, 68138775AB, 68067516AE, 68003303AE, 68003313AB, 52126811AB, 68003304AC, 68047812AA, 68003305AC, 68027793AA, 68067516AA, 68138775AA, 68003311AB, 68032197AA, 68029955AA, 68027794AA, 68047812AD, 68027794AC, 68087359AA, 68027795AA, 68027799AB, 68087360AD, 68003290AC, 68087359AE, 68027794AB, 68087359AF, 68087359AC, 68028415AC, 68027792AA, 68087360AA
Sensen 12140204
Gabriel G64008, 61711
Bilstein 24141727
KYB 554364, 349071
Rancho RS7326, RS77326
NAPA Shocks 911536, NS911536
Duralast TS3431951B

MONROE 911536 Fits Vehicles

  • Jeep Wrangler JK (2018)
  • Jeep Wrangler (2007-2017)

MONROE 911536 Cross References
