MONROE 65160 Magnum Shock Absorber - 22.56 in. Extended Length, Front

$79.99

Limited availability at this price!

In Stock

Get it by Tuesday, Feb 10
No Hassle Return Policy Details
Free Economy shipping on orders over $499 details
Orders placed before 2pm EST will ship same day

MONROE 65160 Part Description

Manufacturer

MONROE

Product Description

Magnum Suspension Shock Absorber

Features & Benefits

  • FOR HARDWORKING COMMERCIAL VEHICLES -- Designed to handle the demands of high mileage and severe use class 6-8 trucks and buses
  • CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger 2-3/8-in. reserve tube holds more fluid to improve performance (most applications)
  • EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/4-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360deg for durability
  • BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (most applications)
  • LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
  • REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
  • IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
  • BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
  • BUY WITH CONFIDENCE -- Comes with Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty

MONROE 65160 Specifications

Product Attributes

Lower Mount Code S6
Upper Mount Code LS53
Dust Shield Included Yes
Includes Bump Stop No
Internal Rebound Bumper No
Hydraulic Lockout No
Part Description Shock Absorber
Internal Construction Type Twin Tube
Adjustable Damping No
Color Black
Finish Painted
Shock Absorber Bore Size 1-3/4 IN
Foam Cell Design No
Shaft Diameter 18 MM
Compressed Length 13.875 IN
Dust Shield Material Metal
Extended Length 22.5625 in
Gas Charged Yes
Lower Mount Type Stem Mount - 3.5/16" Stem Length X 5/8"-11 Thread Pitch
Parts Pack(s) P01482
Travel Length 8.688 in
Upper Mount Type Loop Bushing and Sleeve Mount - 5/8" Sleeve ID X 2" Sleeve OAL
Compressed Length 352.4 MM
Extended Length 573.1 MM
Travel Length 220.7 MM
Shock Absorber Rod End Measuring Point Center of Loop
Shock Absorber Body End Measuring Point Base of Stem
Shock Absorber Bore Size 44.5 MM
Shock Absorber Bore Size 1.75 IN
Adjustable Damping No
Lower Mount Type Stem
Lower Mount Code S6
Upper Mount Code LS53
Mounting Hardware Included Yes
Grade Type Premium
Active or Passive Suspension Passive
Adjustable Compression No
Adjustable Rebound No
Adjustable Ride Height No

Additional Information

MSDS Sheet Number 01168
Country of Origin (Primary) CN
Canadian Harmonizing Tariff Code 8708803000
Harmonized Tariff Code (Schedule B) 8708800050
Harmonized Tariff Code (HTS) 8708801600
UPC 00048598170606
VMRS Code 016008003
UNSPSC 25172011

MONROE 65160 Cross References

BrandPart Number
65160MM, MAE65160
BULLDOG HD SHOCKSHD1215-0125
GABRIEL85080
HALDEXSA65160
MACK20863239, 14QK3108M, 14QK3108, 12QK428M
MERITORM85080
Mack14QK427M, 20374545, 25626048, 20433426
NAPA Shocks65160
OEM20374545, 14QK427M, 20863239, 25626048, 20433426, 14QK3108M
SACHS NORTH AMERICA315621, 471700000445, 315620, 471700000451
Sachs315621, 471700000445, 315620, 471700000451
VOLVO / WHITE / GMC20433426
Volvo20433426
Volvo GM Heavy Truck20433426

MONROE 65160 Fits Vehicles

  • Volvo VHD (2001-2017)
  • Mack GU8 (2008-2010)
  • Mack GU7 (2008-2010)
