MONROE 557002 Part Description
Manufacturer
Product Description
Shock Absorber
Features & Benefits
- FOR RECREATIONAL VEHICLES -- Designed to handle the demands of recreational vehicles that go on cross country adventures and trips close to home
- CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger reserve tube holds more fluid to improve performance (when required)
- EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the bore provides more efficient and consistent control (most applications)
- STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
- BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (when required)
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
MONROE 557002 Specifications
Product Attributes
| Compressed Length | 16.875 IN |
| Compressed Length | 428.6 MM |
| Extended Length | 27.625 in |
| Extended Length | 701.7 MM |
| Travel Length | 10.75 in |
| Travel Length | 273.1 MM |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS54 |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL |
| Upper Mount Code | LS54 |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Gas Charged | Yes |
| Mounting Hardware Included | No |
| Parts Pack(s) | None |
| Body Color | Black |
| Color | Black |
| Cylinder Finish | Painted |
| Dust Shield Included | Yes |
| Dust Shield Material | Metal |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | No |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Part Description | Shock Absorber |
Additional Information
| MSDS Sheet Number | 01164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598557025 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 557002 Cross References
| Brand | Part Number |
|---|---|
| 557002MM | |
| BILSTEIN | 24187022 |
| BULLDOG HD SHOCKS | HD1215-0130 |
| Bilstein | F4BE5E630H0 |
| Bulldog HD | HD12150130 |
| Ford | 5U2Z18V125BFA, E9TZ18124A, E9TZ18124B, F3TZ18125C, F4TZ18124R, F4TZ18124T, F4TZ18125R, F7TZ18125AA |
| Ford Genuine Parts | F3TZ18125C, F7TZ18125AA |
| GABRIEL | 83125 |
| Gold Shock Absorber | 9180241 |
| KONI | 881668SP1 |
| KYB | KG6416 |
| MERITOR | M85904 |
| MONROE VINTAGE | 34779 |
| Monroe Shocks & Struts | 34779 |
| Motorcraft | AA442 |
| NAPA Shocks | 557002 |
MONROE 557002 Fits Vehicles
- Winnebago Adventurer (1992-1998)
- Ford F-59 Commercial Stripped Chassis (1988-1997)
- Ford F-53 Motorhome Chassis (1988-1997)
