(888) 312-8812 Login SignupMONROE 34964 Gas-Magnum Amortiguador
Tap to view 5 more
MSRP: $138.27
$4799
Save $90.28
Limited availability at this price!
In Stock
Get it by Thursday, Jul 2
MONROE 34964 Part Description
Manufacturer
Features & Benefits
- DESIGNED FOR TRUCKS AND VANS -- Engineered for hardworking full-size trucks and vans and features full-displaced valving on compression cycles to deliver controlled ride and handling
- BUILT TO LAST -- Heavy-duty nitrocarburized rod (non-dust shield units only) and sintered iron piston enhance durability for longer service life while self-lubricating fluid seal reduces friction against piston rod to reduce wear
- CONSISTENT RIDE -- OE all-weather fluid contains special modifiers to handle extreme temperatures and help reduce friction and ensure smooth rod reaction
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- LONGER SERVICE LIFE -- Larger bore and bigger 2-in. reserve tube work together to hold more oil for greater capacity to allow the shock to work efficiently for controlled ride and longer service life
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
MONROE 34964 Specifications
Product Attributes
| Compressed Length | 15.75 IN |
| Compressed Length | 400 MM |
| Extended Length | 26.375 in |
| Extended Length | 669.9 MM |
| Travel Length | 10.625 in |
| Travel Length | 269.9 MM |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 1.1/2" Sleeve OAL |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS26 |
| Upper Mount Type | Loop Bushing Mount - 5/8" Bushing ID X 1.5/16" Bushing OAL |
| Upper Mount Code | L1 |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Gas Charged | Yes |
| Mounting Hardware Included | No |
| Parts Pack(s) | None |
| Body Color | Yellow |
| Cylinder Color | Yellow |
| Color | Yellow |
| Cylinder Finish | Painted |
| Dust Shield Included | Yes |
| Dust Shield Material | Metal |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | No |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Part Description | Shock Absorber |
Additional Information
| MSDS Sheet Number | 01168 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598049377 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 34964 Cross References
| Brand | Part Number |
|---|---|
| 34964MM, MAE34964 | |
| ACDelco | 52029 |
| BILSTEIN | 24186032 |
| Bilstein | 2406186 |
| Bulldog HD | HD12140883 |
| Duralast | TS3432152B |
| FCS | 342496, 347083, 347082, 342509, 342510, 342511 |
| FCS AUTO PARTS | 342496 |
| Ford | 1C3Z18124EA, 1C3Z18125LA, 2C3Z18125AA, 2C3Z18125BA, 3C3Z18124AA, 3C3Z18124BA, 3C3Z18124CA, 3C3Z18124DA, 3C3Z18124EA, 3C3Z18124FA, 3C3Z18124GA, 3C3Z18124HA, 3C3Z18124JA, 3C3Z18124KA, 3C3Z18124LA, 3C3Z18124MA, 3C3Z18124NA, 3C3Z18124NB, 3C3Z18124PA, 3C3Z18125CA, 3C3Z18125HA, 3C3Z18125JA, 3C3Z18125KA, 3C3Z18125LA, 3C3Z18125LB, 3C3Z18125LC, 3C3Z18125LD, 3C3Z18125LE, 3C3Z18125MA, 3C3Z18125MB, 3C3Z18125MC, 3C3Z18125MD, 3C3Z18125ME, 5C3Z18124AA, 5C3Z18124BA, 5C3Z18124CA, 5C3Z18124FA, 5C3Z18124KA, 5C3Z18124LA, 5C3Z18124MA, 5C3Z18124NA, 5C3Z18124NB, 5C3Z18124PA, 5C3Z18124RA, 5C3Z18124SA, 5C3Z18124TA, 5C3Z18124VA, 5C3Z18125CC, 5C3Z18125CF, 5C3Z18125CH, 5C3Z18125CJ, 5C3Z18125D, 5C3Z18125E, 5C3Z18125F, 5C3Z18125G, 5C3Z18125LA, 5C3Z18125LB, 5C3Z18125LC, 5C3Z18125LD, 5C3Z18125LE, 5C3Z18125LF, 5C3Z18125MF, 6C3Z18124AGA, 6C3Z18124PBA, 6C3Z18124PHA, 6C3Z18125A, 6C3Z18125B, 6C3Z18125CEA, 6C3Z18125MBG, 6C3Z18125MHA, 7C3Z18124AE, 7C3Z18124AF, 7C3Z18124AGA, 7C3Z18124AH, 7C3Z18124AKA, 7C3Z18124APA, 7C3Z18124ARA, 7C3Z18124EA, 7C3Z18124NBA, 7C3Z18124NCA, 7C3Z18124NDA, 7C3Z18124NEA, 7C3Z18124NGA, 7C3Z18124P, 7C3Z18124PBA, 7C3Z18124PCA, 7C3Z18124PDA, 7C3Z18124PGA, 7C3Z18125CCA, 7C3Z18125CEA, 7C3Z18125CLA, 7C3Z18125CUA, 7C3Z18125CVA, 7C3Z18125CXA, 7C3Z18125LBA, 7C3Z18125LCA, 7C3Z18125LDA, 7C3Z18125LEA, 7C3Z18125LGA, 7C3Z18125M, 7C3Z18125MBA, 7C3Z18125MCA, 7C3Z18125MDA, 7C3Z18125MGA, 8C3Z18124NK, 8C3Z18124PK, 8C3Z18125LK, 8C3Z18125MK, 9C3Z18124A, 9C3Z18124B, 9C3Z18124PDA, 9C3Z18125A, 9C3Z18125B, BC3Z18124A, BC3Z18124AA, BC3Z18124AB, BC3Z18124B, BC3Z18124C, BC3Z18124D, BC3Z18124E, BC3Z18124F, BC3Z18124G, BC3Z18124H, BC3Z18124K, BC3Z18124M, BC3Z18124N, BC3Z18124P, BC3Z18124Q, BC3Z18124R, BC3Z18124T, BC3Z18124U, BC3Z18124V, BC3Z18124W, BC3Z18124X, BC3Z18124Y, BC3Z18124Z, BC3Z18125A, BC3Z18125AA, BC3Z18125AB, BC3Z18125AC, BC3Z18125AG, BC3Z18125AH, BC3Z18125AK, BC3Z18125AM, BC3Z18125AN, BC3Z18125B, BC3Z18125C, BC3Z18125D, BC3Z18125E, BC3Z18125F, BC3Z18125S, BC3Z18125U, BC3Z18125V, BC3Z18125W, BC3Z18125Y, D8TZ18125D, E4TZ18124F, E4TZ18124G, E4TZ18125E, E4TZ18125M, E7TZ18124B, E7TZ18124C, E7TZ18124D, E7TZ18124F, E7TZ18124K, E7TZ18125B, E7TZ18125C, E7TZ18125E, E7TZ18125F, E7TZ18125L, E7TZ18125M, E7XZ18124D, E7XZ18124F, E7XZ18125D, E7XZ18125G, F2TZ18124R, F2TZ18125A, F2TZ18125P, F3TZ18124B, F3TZ18125B, F4TZ18124B, F4TZ18124D, F4TZ18124E, F4TZ18124F, F4TZ18124G, F4TZ18124H, F4TZ18124J, F4TZ18124K, F4TZ18125B, F4TZ18125C, F4TZ18125D, F4TZ18125E, F4TZ18125F, F4TZ18125G, F4TZ18125H, F4TZ18125L, F4TZ18125N, F5TZ18124AA, F5TZ18125AA, F65Z18125DC, F75Z18124AA, F75Z18124BA, F75Z18125AG, F75Z18125DA, F75Z18125DC, F75Z18125HB, F75Z18125HC, F75Z18125JB, F75Z18125PB, F75Z18125PC, F7AZ18124RB, F7AZ18124ZG, F7AZ18125YA, F7AZ18125ZA, F81Z18124AA, F81Z18124AB, F81Z18124AC, F81Z18124AE, F81Z18124AF, F81Z18124AG, F81Z18124AH, F81Z18124AJ, F81Z18124AK, F81Z18124AL, F81Z18124AM, F81Z18124AP, F81Z18124BA, F81Z18124BB, F81Z18124BC, F81Z18124BD, F81Z18124BE, F81Z18124BF, F81Z18124BG, F81Z18124BH, F81Z18124BJ, F81Z18124BK, F81Z18125CA, F81Z18125CB, F81Z18125CC, F81Z18125CD, F81Z18125CE, F81Z18125CF, F81Z18125CG, F81Z18125CH, F81Z18125CJ, F81Z18125CK, F81Z18125CL, F81Z18125CM, F81Z18125CN, F81Z18125CP, F81Z18125CQ, F81Z18125CR, F81Z18125CS, F81Z18125CT, F81Z18125CV, F81Z18125CW, F81Z18125CX, F81Z18125CZ, F85Z18124LA, F8AZ18125JA, FOTZ18125A, FOTZ18125D, BC3418080DJC, BC3Z18125AQ |
| GABRIEL | G63456, 58456, 58810, 58461, 61530 |
| Gabriel | G63461 |
| Gold Shock Absorber | 9131058 |
| HALDEX | SA34964 |
| KYB | KG5493, 344079, 565124, 554363, 344413, 565063, 565100, KG54332, 345072, KG54333, 565123, 555056, KG5443, 554366, 565091, 345070, KG5044, 344419, 344382 |
| MERITOR | MG60081 |
| MOTORCRAFT | ASH12184 |
| MasterPro Shocks and Struts | FD136 |
| Monroe Shocks & Struts | 911039, 32386, 210403 |
| NAPA Proformer | SH81510 |
| NAPA Shocks | 76964 |
| OEM | BC3Z18125AN, 7C3Z18125CUA, 7C3Z18125CVA, 7C3Z18125CXA, BC3Z18125D |
| SACHS NORTH AMERICA | 30256 |
| Sachs | 30256 |
| Sensen | 12140137 |
| TRW | JGT4080S |
MONROE 34964 Fits Vehicles
- Thor Motor Coach Chateau Super C (2013-2016)
- Thor Motor Coach Outlaw (2014-2015)
- Ford F-550 Super Duty (2012-2016)
- Ford F-450 Super Duty (2012-2016)
- Ford F-250 HD (1997)
- Ford F-350 Super Duty (1999-2016)
- Ford F-350 (1985-1997)
- Ford F-250 (1992-1996)
- Ford F-150 (1990-1996)
