MONROE 34524 Part Description
Manufacturer
Product Description
Gas-Magnum Suspension Shock Absorber
Features & Benefits
- DESIGNED FOR TRUCKS AND VANS -- Engineered for hardworking full-size trucks and vans and features full-displaced valving on compression cycles to deliver controlled ride and handling
- BUILT TO LAST -- Heavy-duty nitrocarburized rod (non-dust shield units only) and sintered iron piston enhance durability for longer service life while self-lubricating fluid seal reduces friction against piston rod to reduce wear
- CONSISTENT RIDE -- OE all-weather fluid contains special modifiers to handle extreme temperatures and help reduce friction and ensure smooth rod reaction
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- LONGER SERVICE LIFE -- Larger bore and bigger 2-in. reserve tube work together to hold more oil for greater capacity to allow the shock to work efficiently for controlled ride and longer service life
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee
MONROE 34524 Specifications
Product Attributes
| Lower Mount Code | LS26 |
| Upper Mount Code | LS49 |
| Dust Shield Included | Yes |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Compressed Length | 14.75 IN |
| Dust Shield Material | Metal |
| Extended Length | 24.75 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 1.1/2" Sleeve OAL |
| Parts Pack(s) | None |
| Travel Length | 10 in |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 5/8" Sleeve ID X 1.3/16" Sleeve OAL |
| Compressed Length | 374.7 MM |
| Extended Length | 628.7 MM |
| Travel Length | 254 MM |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS26 |
| Upper Mount Code | LS49 |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
Additional Information
| MSDS Sheet Number | 01170 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598050977 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 34524 Cross References
| Brand | Part Number |
|---|---|
| 34524MM, FT4Z5806010AC | |
| Autopart International | 2701603107 |
| BILSTEIN | 24186032 |
| Duralast | TS3240272B |
| FCS | 347082 |
| Ford | 1C3Z18125DA, 5C3Z18124JA, 5C3Z18125DA, 7C3Z18124HA, 7C3Z18124NJA, 7C3Z18125DCA, 7C3Z18125DJA, 7C3Z18125LJA, 9C3Z18125C, BC3Z18124AC, BC3Z18124J, BC3Z18124Q, BC3Z18124W, BC3Z18125AD, BC3Z18125AP, BC3Z18125AQ, BC3Z18125B, BC3Z18125G, BC3Z18125H, BC3Z18125X, FC3Z18124A, FC3Z18124B, FC3Z18125A, FC3Z18125B, BC3418080DCC |
| GABRIEL | 77968, G63963, 77969 |
| KYB | 554362, 3440029, 565124, 554363, 344079, 344413, 565063, 554388, 349146, 555056, KG5443, 345070, KG5044 |
| MOTORCRAFT | ASH24500 |
| NAPA Shocks | 76524 |
| OEM | BC3Z18125AP |
| PM Auto | PM6001548 |
| Rancho | RS5116, RS55116 |
| Sensen | 12150007 |
MONROE 34524 Fits Vehicles
- Thor Motor Coach Chateau Super C (2013-2016)
- Thor Motor Coach Outlaw (2014-2015)
- Ford F-550 Super Duty (2005-2016)
- Ford F-450 Super Duty (2005-2016)
