MONROE 32290 Part Description
Manufacturer
Product Description
Monro-Matic Plus Suspension Shock Absorber
Features & Benefits
- CONSISTENT RIDE -- Velocity Proportional Valving (VPV) technology and all-weather fluid containing special additives to reduce friction and ensure smooth rod reaction and an overall smoother ride
- RELIABLE PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration
- RESTORES RIDE AND HANDLING -- Larger bore provides more efficient damping control to provide consistency and a smooth ride (where applicable)
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear while banded piston and bronze reinforced guide provide durability
- GET MORE MILES FROM YOUR RIDE -- Designed and validated to meet OE spec and deliver consistent performance
MONROE 32290 Specifications
Product Attributes
| Lower Mount Code | LS28 |
| Upper Mount Code | LS28 |
| Dust Shield Included | Yes |
| Includes Bump Stop | No |
| Internal Rebound Bumper | Yes |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Compressed Length | 11.25 IN |
| Dust Shield Material | Metal |
| Extended Length | 17.125 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 1.5/8" Sleeve OAL |
| Parts Pack(s) | None |
| Travel Length | 5.875 in |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 41.28MM Sleeve OAL |
| Compressed Length | 285.8 MM |
| Extended Length | 435 MM |
| Travel Length | 149.2 MM |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
Additional Information
| MSDS Sheet Number | 1164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598026613 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 32290 Part Interchanges
| Brand | Part Number |
|---|---|
| Chrysler | 4684681, 4684681AB, 4684682, 4684682AB, 4684840, 4721340AA, 4737526, 4743127, 4743128, 4743129, 4743224AA, 4743225AA, 4743226AA, 4743227AA, 4743228AA, 4743229AA, 4743230AA, 4743231AA, 4743232AA, 4743233AA, 4743411AB, 4743412, 4743412AB, 4743412AC, 4743413AB, 4743413AC, 4743642, 4743643, 4766124, 4766452AA, 4797641, 4797642, 4897451AA, 5066333AA, 5066334AA, 5066336AA, 5066337AA, 5135538AA |
| Dodge | 4684681, 4684681AB, 4684682, 4684682AB, 4684840, 4721340AA, 4737526, 4743125, 4743127, 4743128, 4743129, 4743224AA, 4743225AA, 4743226AA, 4743227AA, 4743228AA, 4743229AA, 4743230AA, 4743231AA, 4743232AA, 4743233AA, 4743411, 4743411AB, 4743412, 4743412AB, 4743412AC, 4743413AB, 4743413AC, 4743547, 4743642, 4743643, 4743686, 4766124, 4766452AA, 4797640, 4797641, 4797642, 4897451AA, 5066333AA, 5066334AA, 5066336AA, 5066337AA, 5135538AA |
| Plymouth | 4684681, 4684681AB, 4684682, 4684682AB, 4684840, 4737526, 4743125, 4743127, 4743128, 4743129, 4743411, 4743411AB, 4743412, 4743412AB, 4743412AC, 4743642, 4743643, 4766124, 4797640, 4797641, 4797642, 4897451AA |
| Ultra Spring Seat | G63690 |
| Gabriel | 81878, 61605, G63690 |
| KYB | 344080, KG5457, SR2001, SR2002 |
| AutoZone | TS34-31732B, TS3431732B |
| FCS Auto Parts | 342445 |
| ACDelco | 520253, 52089 |
| NAPA Response | 94185 |
| FCS | 342445 |
| Sensen | 12140144 |
| Duralast | TS3431732B |
| Monroe Shocks & Struts | 59359 |
| MasterPro Shocks and Struts | SH100 |
| NAPA Proformer | SH81878 |
MONROE 32290 Fits Vehicles
- Plymouth Voyager (1995-2000)
- Plymouth Grand Voyager (1995-2000)
- Dodge Grand Caravan (1995-2007)
- Dodge Caravan (1995-2007)
- Chrysler Voyager (1997-2005)
- Chrysler Town & Country (1995-2007)
- Chrysler Grand Voyager (1997-2002)
MONROE 32290 Cross References
We have 9 alternatives for the 32290 by MONROE:
