(888) 312-8812 Login SignupMERITOR HM518445 Bearing Cone, 3.500 in. Inside Diameter, Standard, 1.563 in. Thickness, Inner/Outer
MSRP: $107.95
$4549
Save $62.46
Limited availability at this price!
In Stock
Get it by Friday, Aug 7
MERITOR HM518445 Part Description
Manufacturer
Product Description
Standard Bearing Cone Tp Trailer Inner Or Outer
Features & Benefits
- Tapered rollers carry wheel-end load through controlled rolling contact
- Machined cone surface pairs with the matching bearing cup
- Rough cone contact can create heat once rotation begins
- Trailer bearing service gains fresh metal at the inner or outer position
- Smooth rolling action helps the bearing set rotate with less drag
Meritor Tapered Bearing Cone
Trailer bearing service can rely on the Meritor Tapered Bearing Cone when the rolling half of the bearing set needs clean contact again. The cone has machined rollers and a tapered race profile that should feel smooth before it goes into the hub or axle location. Pitting, heat marks, or rough roller movement can turn into noise and heat once the wheel end returns to load. Through Meritor HM518445, the bearing set receives a fresh cone surface that works with the matching cup to guide rotation under pressure.
| Axle Application | Trailer |
| Axle Series | TP |
| Bearing Brand | Timken |
| Bearing Location | Inner/Outer |
| Bearing Type | Standard |
| Hub Type | Conventional |
| Inside Diameter (in.) | 3.500 in. |
| Inside Diameter (mm) | 88.9mm |
| Thickness (in.) | 1.563 in. |
| Thickness (mm) | 39.688mm |
| Type | Cone |
| VMRS Code | 018-005-001 |
Meritor Bearing Cone
The Meritor bearing cone is designed for maximum performance for differentials, transmissions, and wheel end applications. It is manufactured using the exact same process as Meritor production bearings.
Features & Benefits
- Fully-sealed design with grease barriers keeps lubricant in and contaminants out
- Made of high-grade raw materials with fewer impurities for improved durability and performance
- Advanced through-hardened construction greatly improves tensile strength
- Precise internal geometry ensures accuracy and reliability even in demanding applications
- Smooth rolling action helps the bearing set rotate with less drag
MERITOR HM518445 Specifications
Product Attributes
| Axle Application | Trailer |
| Axle Series | TP |
| Bearing Brand | Timken |
| Bearing Location | Inner/Outer |
| Bearing Type | Standard |
| Brand | Meritor |
| Hub Type | Conventional |
| Inside Diameter (in.) | 3.500 in. |
| Inside Diameter (MM) | 88.9mm |
| Pallet Quantity | 384 |
| Thickness (in.) | 1.563 in. |
| Thickness (mm) | 39.688mm |
| Type | Cone |
| Weight | 4.70 |
| Thickness | 1.563 in. |
| Inside Diameter | 3.500 in. |
MERITOR HM518445 Cross References
| Brand | Part Number |
|---|---|
| 2HM518445, TMHM518445 | |
| Automann | 182HM518445, 182HM518445SV |
| BCA | HM518445 |
| NAVISTAR | FLTHM518445 |
| SKF | HM518445, HM518445VP, HM518445 VP |
| STEMCO | KHM518445, HM518445 |
| TIMKEN | HM518445 |
