RAYBESTOS 680508P DISC BRK ROTOR

(0)

$151.49

Limited availability at this price!

In Stock

Get it by Tuesday, Aug 18
No Hassle Return Policy Details
Free Ground shipping on orders over $499 details

RAYBESTOS 680508P Part Description

Manufacturer

RAYBESTOS

Product Description

Raybestos Specialty - Police Brake Rotor

Application Summary

2020-2010 Ford F-150 Front, 2021-2007 Ford Expedition Front, 2021-2007 Lincoln Navigator Front, 2014-2012,2010 Ford Lobo Front

Features & Benefits

  • Enhanced Iron Material
  • Raybestos® Police Rotors are made from an enhanced iron material for higher thermal conductivity to keep brakes running cool, quiet, and vibration free.
  • Raybestos(R) Police Rotors are made from an enhanced iron material for higher thermal conductivity to keep brakes running cool, quiet, and vibration free.
  • Cooling Vanes
  • Police rotors have a unique and specific vane design. This design improves pad force distribution and enhances cooling airflow throughout the rotor, allowing for optimal heat dissipation – something quite important during pursuit driving.
  • Police rotors have a unique and specific vane design. This design improves pad force distribution and enhances cooling airflow throughout the rotor, allowing for optimal heat dissipation - something quite important during pursuit driving.
  • Grey Fusion 4.0® Coating
  • Grey Fusion 4.0(R) Coating
  • Our Police rotors are coated with a full Grey Fusion 4.0® coating, providing the durability police vehicles need. This coat of armor provides protection against the elements, whether it be in heat, cold, rain, ice or snow.
  • Our Police rotors are coated with a full Grey Fusion 4.0(R) coating, providing the durability police vehicles need. This coat of armor provides protection against the elements, whether it be in heat, cold, rain, ice or snow.
  • Turned Finish
  • A turned finish minimizes noise and improves responsiveness for smoother stops.
  • Low Initial Lateral Run-out and Thickness Variation
  • Our Police rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation and an extended pad life.
  • SAE Standard for Tensile Strength
  • Police rotors are mill balanced and 100 percent validated.

RAYBESTOS 680508P Specifications

Product Attributes

ABS Tone Ring Included No
Center Hole Diameter 3.54 IN
Center Hole Diameter 89.9 MM
Conventional Or Drum-In-Hat Type Rotor Conventional
Directional or Non-Directional Brake Surface Non-Directional
Discard Thickness 1.26 IN
Discard Thickness 32 MM
Harmonize Code 8708.30.5030
Material Cast Iron
Mounting Bolt Hole Circle Diameter 5.315 IN
Mounting Bolt Hole Circle Diameter 135 MM
Mounting Bolt Hole Diameter 0.636 IN
Mounting Bolt Hole Diameter 16.15 MM
Mounting Bolt Hole Quantity 6
Nominal Thickness 1.339 IN
Nominal Thickness 34 MM
Outside Diameter 13.78 IN
Outside Diameter 350 MM
Overall Height 1.95 IN
Overall Height 49.55 MM
Salability Restrictions No
Solid Or Vented Type Rotor Vented
Stud/Lug Hole Quantity 6
UNSPSC Code 25171715

Additional Information

Country of Origin (Primary) CN
Canadian Harmonizing Tariff Code 8708309990
Harmonized Tariff Code (HTS) 8708305030
UPC 00829352847312

RAYBESTOS 680508P Cross References

BrandPart Number
ADVANCE AUTO PARTSBD126433, G09290SD, YH145698C, YH145698P
AUTOPARTSOURCE592845
AUTOXTRAAX900846, AX900848
AUTOZONE42251, 42251DG, 42251DL
AutoZone42251SD
AutoxtraAX900846P
BENDIXPRT5698, SDR5698
BOSCH20011442
BRAKEBEST20011442, 680508, 680508FZN, 680508P, 680508PER, 680508R, 680508RGS
CENTRIC120.65119, 121.65119, 126.65119CSL, 126.65119CSR, 126.65119SL, 126.65119SR, 127.65119CR, 127.65119L, 127.65119R, 127.65119CL, 128.65119CL, 128.65119CR, 128.65119L, 128.65119R, 227.65119L, 227.65119R, 320.65119, 320.65119F, 321.65119
Centric Parts120.65119, 121.65119, 126.65119CSL, 126.65119CSR, 126.65119SL, 126.65119SR, 127.65119CL, 127.65119CR, 127.65119L, 127.65119R, 128.65119CL, 128.65119CR, 128.65119L, 128.65119R, 227.65119L, 227.65119R, 320.65119, 320.65119F, 321.65119
DURA CORPBR54153, BR900368, BR900846, BR900846-02, BR900848
DuraGo60410, 900368, 900846, BR60410, BR900368, BR900846, BR90084602, BR900846-02
Dynamic Friction Company604-54204
Eurorotor54233
FORD7L1Z1125A, 7U2Z1V125HA, 7U2Z1V125HC, 8L1Z1125A, 9L1Z1125A, AL3Z1125B, CL3Z1125B, CL3Z1125D, FL3Z1125A, JL3Z1125A
FordJL3Z1125B, JL3Z1125C
MONROE BRAKESBD126433
MOTORCRAFTBRR155, BRR227, BRRF293
NEWTEK AUTOMOTIVE54153
Neotek Drums and Rotors1071038GF
Newtek Automotive USA54153
POWERSTOPAR85108EVC
PROMAX14-54153, 20-54153
QUALIS42251
TopNotchTN680508GEO
UAP2054153, 54153
Ultra Brake54233
WABCOPS900846
WABCO - ArchivedPS900846
WAGNERBD126433E
WAGNER BRAKEBD126433E, BD126433
WINHERE6620754
WORLDPAC1407-75229, 1427-499345

RAYBESTOS 680508P Fits Vehicles

  • Ford Lobo (2010, 2012-2014)
  • Ford F-150 (2010-2020)
  • Lincoln Navigator (2007-2023)
  • Ford Expedition (2007-2021)
