(888) 312-8812 Login SignupMERITOR FS9101 Air Suspension Spring, 10.25 in. Bead Plate Diameter Bottom, 9.00 in. Bead Plate Diameter Top
Tap to view 5 more
MSRP: $506.45
$23999
Save $266.46
Limited availability at this price!
In Stock
Get it by Friday, Jul 24
MERITOR FS9101 Part Description
Manufacturer
Product Description
Air Suspension Spring
Features & Benefits
- Cushions load changes before harsh movement reaches the frame structure
- Seals compressed air between the mounting plates through suspension travel
- Responds to height-control valve changes as vehicle load shifts
- Lessens sag concerns tied to aged rubber or leaking spring bodies
- Fits air-ride service where pressure retention is the main complaint
Meritor Air Suspension Spring
The Meritor Air Suspension Spring is the part to inspect after a trailer or truck corner sits low, leaks down, or rides harsher than the rest of the suspension. Air springs carry load through air pressure and rubber movement, so cracks, seepage, or tired bead areas can change both ride height and ride feel. This replacement spring brings the pressure-carrying section back into the suspension stack without changing the axle hardware around it. Once the old unit is removed and the mounting surfaces are cleaned, the Meritor FS9101 brings the air spring position back into service.
| Aftermarket Extended Warranty - General | 3 Years / 300K Miles |
| Application | Holland (Neway) 90557008, 90557009, 90557082; Ridewell 1003589101C; Reyco 12883-01; Silent Drive; Truckstell (Marion Mfg.) 63647; Mfg. SV.# Neway 90044201; Watson & Chalin AS-0040 |
| Bead Plate Diameter Bottom | 10.25 in. |
| Bead Plate Diameter Top | 9.00 in. |
| Collapsed Height | 9.70 in. |
| Convoluted Style | 1T Reversible Sleeve |
| Max. Height | 25.60 in. |
| Part Diameter | 10.12 in. |
| Piston Height | 7.40 in. |
| Stud Configuration-Bottom | 4 |
| Stud Configuration-Top | 2 |
| Stud Mount-Bottom Flat | Flat |
| Stud Mount-Top Flat | Stud |
| VMRS Code | 016-008-000 |
Meritor Air Suspension Spring
Meritor air suspension spring protects tractors and trailers from road shocks and keep your ride a comfortable one. This aftermarket air spring covers a wide range of OEM specifications at affordable prices.
Features & Benefits
- Lightweight, high-strength pistons with support washers provide exceptional strength and durability
- Made of premium-grade steel and aluminum with electrostatic coating for oxidation resistance
- Special chromium coating on bead plate protects against rust, corrosive chemicals, and harsh operating environments
- Cushions load changes before harsh movement reaches the frame structure
- Fits air-ride service where pressure retention is the main complaint
MERITOR FS9101 Specifications
Product Attributes
| Aftermarket Extended Warranty - General | 3 Years / 300K Miles |
| Application | Holland (Neway) 90557008, 90557009, 90557082; Ridewell 1003589101C; Reyco 12883-01; Silent Drive; Truckstell (Marion Mfg.) 63647; Mfg. SV.# Neway 90044201; Watson & Chalin AS-0040 |
| Bead Plate Diameter Bottom | 10.25 in. |
| Bead Plate Diameter Top | 9.00 in. |
| Brand | Meritor |
| Collapsed Height | 9.70 in. |
| Convoluted Style | 1T Reversible Sleeve |
| Max. Height | 25.60 in. |
| Pallet Quantity | 32 |
| Part Diameter | 10.12 in. |
| Piston Height | 7.40 in. |
| Product Category | Genuine OE Product |
| Stud Configuration-bottom | 04 |
| Stud Configuration-top | 02 |
| Stud Mount-bottom Flat | Flat |
| Stud Mount-top Flat | Stud |
| Weight | 16.60 |
| Air Spring Type | Reversible Sleeve |
| Max Height | 25.60 in. |
MERITOR FS9101 Cross References
| Brand | Part Number |
|---|---|
| Airtex | AB1DK23L9101 |
| Automann | 566CT64279 |
| BWP | M3515 |
| CONTITECH | 2303531, 91019, 91019P315 |
| Continental-ContiTech | 2303531, 64279, 91019P315, 91019 |
| DAYTON PARTS BATCO | 3529101, 1R12076, 1R12103, S11566 |
| FIRESTONE | W013589101, 1T15K2, 1T15M9, 9101, 9102 |
| FLAGG | 8315 |
| Firestone Ride-Rite | 1T15K2, 1T15M9, 9101, 9102, W013589101 |
| Ford | 1T15K2, 1T15M9 |
| Fruehauf | MNW90557009S |
| GOODYEAR | 1R12076, 1R12103, 1R12113, 1R12116, 1R12135 |
| HALDEX | CS112103, CS112113 |
| HENDRICKSON | B3842, S10443, 9101, 9102 |
| HENDRICKSON TURNER | S3842 |
| NEW LIFE/FLEETCRAFT | 1R12103, 1R12113 |
| NEWAY | AR14151FG, 57009101, 90044201, 90044653, 90054218, 90557008, 90557009, 90557032, 90557082 |
| PARTS AMERICA | 9101, 9102 |
| POWER EQUIPMENT -PDC | 9101 |
| PROVINCIAL WHSE -CAN | M6510 |
| REYCO | 12883, 1288301 |
| RIDEWELL | S5828C, S740C, 1003589101C |
| Reyco Granning | 12883, 1288301 |
| Ridewell Corp | 1003589101C, S5828C, S740C |
| S AND G | AS5099101 |
| SAF HOLLAND | 90557009 |
| SAF-HOLLAND | 90557009 |
| SIRCO BRAKE | AS9101 |
| TW HEAVY VEHICLE PTS | 1R12103, 1R12113, 90557009, 90557032 |
| Trailmobile | 3090054218, 3090557008, 3090557009, 3090557032, GY1R12103 |
| UCF AMERICA | AB1R12103, AB1R12113 |
| Volvo | 3130490 |
| WATSON CHALIN | AS0040, AS00401F |
| WORLD AMERICAN | WA01-9101C |
MERITOR FS9101 Customer Reviews
No reviews yet
Be the first to review this product!
MERITOR FS9101 Manufacturer Information
Meritor®, whose roots could be traced back to 1909, is backed by over 100 years of industry experience plus a massive portfolio of products for various industries. In 1998, it made several acquisitions, including Volvo Trucks' heavy vehicle manufacturing operation in Sweden, Euclid Industries, and Lucas Varity's Heavy Vehicle Braking Systems division. Such investments solidify Meritor's position as the leading global supplier of brakes, axles, drivelines, transmissions, suspensions, tire inflations systems, and a whole lot of parts, hardware, and accessories for the automotive, truck, trailer, rail cars, bus and coach, and many other applications. Its "Run with the Bull" global brand identity further strengthens its commitment to provide the industry with durable products, unparalleled service and support, and continuous innovation.
