Gates G22832-2424 - Female British Standard Parallel Pipe O-Ring Swivel - 90 Bent Tube
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
GATES part description
Product Description
Female British Standard Parallel Pipe O-Ring Swivel - 90 Bent Tube
Features & Benefits
- "Bite-the-wire" crimp for improved coupling retention
- “Bite-the-wire” crimp for improved coupling retention
- Tested to an industry-leading 1,000,000 impulse cycles
- +250 Deg. F temperature capability for longer assembly life
- Environmentally-friendly TuffCoat plating for 347 percent better corrosion resistance than the SAE Standard
Product Attributes
| Thread Size | 1 1/2-11 |
| Inside Diameter | 1.5 IN |
| Hydraulic Hose Recommendation | Gates Extremely High Pressure Hydraulic Hose (-24 & -32) |
| Nut Hex Size | 50 MM |
| Drop Length | 3.93 IN |
| Cut-Off Length | 4.76 IN |
| Length | 7.66 IN |
| Coupling Description | GlobalSpiral Plus Female British Standard Parallel Pipe O-Ring Swivel - 90 Bent Tube |
| Industrial Description | 24GSP-24FBSPORX90 |
| Inside Diameter | 38.1 MM |
| Drop Length | 99.8 MM |
| Cut-Off Length | 121 MM |
| Length | 194.6 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 7326908688 |
| Country of Origin (Primary) | US |
| UPC | 00770075424420 |
| VMRS Code | 059032012 |
| UNSPSC | 31163000 |
Part Interchanges
