HALDEX part description

Product Description

Pure Air™ Air Dryer, 12V

Features & Benefits

  • Engineered using state-of-the-art technology for maximum efficiency
  • Boasts triple-action—cooling, filtering, and drying the air
  • Has a standard size and offers ease of installation
  • Built to offer flexibility since air dryer may be mounted horizontally or vertically
  • Can be serviced from either end
  • All Haldex air dryers are manufactured to meet the highest quality standards

Haldex Pure Air™ Air Brake Dryer

Prevent air-line freeze-ups with the Haldex Pure Air™ air brake dryer. Manufactured by a brand with more than 100 years of engineering expertise, this air dryer ensures only clean, dry air is being supplied to the air brake system as it helps filter most liquid and water vapor from the compressor discharge air.

Product Attributes

Air Port Thread Diameter 1/2 in.
Burst Pressure 500 PS
Drying Method Coalescence/Desiccant
Exhaust Port Diameter 1 in.
Freight Class 70
Governor Port Diameter 1/8 in.
Heater Included Yes
Heater Voltage 12V
Inlet Port Diameter 1/2 in.
Length 18-1/4 in.
Material Aluminum
Maximum Compressor Capacity 24 SCFM
Mounting Bracket Included Yes
Mounting Position Horizontal or Vertical
New Or Remanufactured New
Outlet Port Diameter 1/2 in.
Port Quantity 4
Series Pure Air™
Wattage 60 Watts
Width 7.49 in.

Additional Information

Country of Origin (Primary) US
Harmonized Tariff Code (Schedule B) 8421398015
Harmonized Tariff Code (HTS) 8421398015
Remanufactured Part N
Warranty Distance 100000
Warranty Distance UOM MI
Warranty Special See Haldex Aftermarket Product warranty Policy (L20221W).pdf
Warranty Time 12
Warranty Time UOM MO
UPC 00767653011189
VMRS Code 013010252

Part Interchanges

Haldex® is a Sweden-based manufacturer specializing in brake and air suspension systems for heavy duty vehicles. Its product line consists of brake components for wheel ends, including disc brakes, brake adjusters, and actuators. It also offers air control products such as compressed air dryers, valves, ABS, and EBS. All these Haldex products are designed with safety and efficient operation in mind, cutting down on potential hazards and maintenance costs in the long run. Today, Haldex runs manufacturing and R&D facilities in 19 countries across four continents. It is dedicated to producing high-quality brake and suspension parts for its customers all around the world as well as developing new technologies for the future.
HALDEX KN33000 Cross Reference

We have 2 alternatives for the KN33000 by HALDEX:
