Cole Hersee 956-3125-BX - 956 Heavy Duty Series Ignition Switch - 3 Position
- Part Number
- 956-3125-BX
- Manufacturer
- COLE HERSEE
- Description
-
956 Heavy Duty Series Ignition Switch - 3 Position
details
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
COLE HERSEE part description
Technical Specifications:
| Description | Anti-Restart Ignition Switch |
| Terminals | 4 screw |
| Actuator | Coded Tumbler Lock 2 Keys |
| O-Ring seal in stem | No |
| Ground terminal | No |
| Number of positions | 3 |
| Positions | Off-Ign/Acc-Ign/Start |
| Accessory | 30 A at 12 Vdc |
| Ignition/Run | 10 A at 12 Vdc |
| Start | 10 A at 12 Vdc |
| Case material | Plated Steel |
| Removable key | Yes |
| Min qty | No |
| Sample capable | No |
Littelfuse Ignition Switches are designed for universal applications within harsh environments. Their mounting, body, and actuator features are designed for ease-of-use and extended product lifecycle.
The 956 Heavy Duty Series is our most robust series of Ignition Switches, providing reliable circuit control for vehicle ignition.
Features & Benefits
- Key removable in “Off” Position Only (where actuator applicable)
- Ignition Proof to SAE J259
- 5 screw terminals.
- Coded lock & keys.
- Gasket-sealed, Shutter lock seal, O-ring seal in stem.
- Ground terminal.
- 1"-24 bushing.
- Off-Ign/Acc-Ign/Start. Spring return to Ign/Acc. Key removable at Off.
- Ratings at 12V DC: 10A Accessory, 10A Ignition, 5A Start, 1A Ground.
Cole Hersee® is highly valued in the heavy duty truck industry. It is a leading manufacturer of heavy-duty battery master switches that are widely used as OE equipment by leading heavy-duty vehicle manufacturers. These switches are essential safety components for trucks as they help prevent theft, tampering, electrical fires, and battery drain. Founded in 1924, Cole Hersee is committed to improving vehicle safety by partnering with ECCO Safety Group Australia (ESGA) to establish and implement safety standards for trucks that drive onto mining sites. Its products are also manufactured in its ISO 9001:2008-certified facility and undergo strict testing to ensure safety and reliability.
