(888) 312-8812 Login SignupEUCLID E-5929-R Wheel Lug Stud, Shoulder, 1.12 in. Collar Diameter, 0.200 in. Collar Length, 3 in. Hub End Length
Tap to view 2 more
MSRP: $17.00
$1599
Save $1.01
Limited availability at this price!
In Stock
Get as soon as Wednesday, Oct 14
EUCLID E-5929-R Part Description
Manufacturer
Product Description
Wheel End Hardware, Right Hand Wheel Stud
Features & Benefits
- Threads into paired wheel hardware from both sides of the stud body
- Shoulder-style center section steadies the stud within the wheel-end stack
- Grade 8 steel gives the fastener a firm, heavy-duty service feel
- Collar flats improve handling when lining up the stud during installation
- Aluminum disc wheel use ties the hardware to the correct wheel type
Euclid Right Hand Double End Wheel Stud
For aluminum disc wheel fastening, the Euclid Right Hand Double End Wheel Stud sets up the wheel end with threaded contact on both sides of the hub stack. Its Grade 8 body has the firm, machined feel of a shoulder-style stud, with flats at the collar and clean threads made for nut engagement from each end. In dual wheel service, this stud works through the clamping path instead of seating like a headed stud against the back of the hub. The double-end shape fits setups where the hub side and wheel side both use a controlled fastening surface. Right-hand thread direction also affects wheel-end matching, since the stud has to work with the correct cap nut and wheel hardware. The Euclid E-5929-R fits aluminum disc wheel applications that use this shoulder-style double-ended stud.
EUCLID E-5929-R Specifications
Product Attributes
| Brand | Euclid |
| Caution | Do not use with steel wheel. Cap nut will bottom out before tightening against wheel. |
| Collar Across Clip | 0.94 in. |
| Collar Diameter | 1.12 in. |
| Collar Length | 0.200 in. |
| Collar Style | Clipped |
| Grade Type | 8 |
| Hub End Body Diameter | 0.786 in. |
| Hub End Length | 3 in. |
| Hub End Thread | 3/4"-16 |
| Hub End Thread Length | 1 7/16 in. |
| Overall Length | 5 3/16 in. |
| Serration | Plain |
| Type | Shoulder |
| Wheel End Length | 2 in. |
| Wheel End Body Diameter | Thread |
| Wheel End Thread | 42433 |
| Wheel End Thread Direction | Right Hand |
| Wheel End Length To First Thread | 0.38 in. |
| Wheel End Thread Length | 1.62 in. |
| Wheel End Threads Per Inch | 16 |
EUCLID E-5929-R Cross References
| Brand | Part Number |
|---|---|
| E-5929R, W459, R005929R | |
| AUTOMANN | 2017016R |
| BWP | M2406, M2407, M240707 |
| BWP-NSI | M-2406 |
| DAYTON PARTS BATCO | 131019R |
| DORMAN | 610-0481.10 |
| Freightliner | 11971416 |
| LELAND | W459 |
| Macpek | X2055 |
| NAPA | 6412360 |
| NUTURN - CAN | W459 |
| NWRA | X2055 |
| PROVINCIAL WHSE -CAN | M2706 |
| SPICER | 501028R |
| WORLD TRUCK | 1542001R |
