(888) 312-8812 Login SignupEUCLID E-3197 Leaf Spring Center Bolt, 12.00 in. Bolt Length, 0.75 in. Head Diameter, 9.50 in. Minimum Thread Length
Tap to view 1 more
$5520
Package Price for 12 Units
@ $4.60 per unit
Limited availability at this price!
In Stock
Get it by Friday, Jul 10
EUCLID E-3197 Part Description
Manufacturer
Product Description
Suspension Hardware, Spring Center Bolt
Features & Benefits
- Alloy steel provides high shear strength within the leaf pack
- Hex nut includes necessary tracking retention properties
- Maintains tight vertical clamping tension between suspension parts
- Prevents single spring leaves from migrating out of line
Euclid Leaf Spring Center Bolt
Clamping multi-leaf spring packs firmly together prevents suspension shifting when choosing the Euclid Leaf Spring Center Bolt. The high-strength center bolt keeps individual spring leaves properly indexed throughout the entire spring pack. Incorporating the Euclid E-3197 into your spring rebuild helps keep the leaf spring pack securely aligned under load. It includes a matching high-tensile nut to complete the installation and maintain the correct chassis height over uneven asphalt.
| Bolt Length | 12.00 in. |
| Head Diameter | 0.75 in. |
| Head Height | 0.4375 in. |
| Hex | 0.75 in. |
| Includes | Nut, Spring Center Bolt |
| Min. Thread Length | 9.50 in. |
| Notes | Spring Center Bolt, Head Height 7/16 |
| Nut | E5032 |
| OEM | Reyco |
| Part Type | Bolt |
| Suspension Model | Reyco/Granning 21B, 73, 74B, 79KB, 83, 101, 101A, 102, 102AR / Spicer 36 |
| Thread Diameter | 0.500 in. |
| Threads per Inch | 20 |
| VMRS Code | 016-005-000 |
Features & Benefits
- Prevents single spring leaves from migrating out of line
EUCLID E-3197 Specifications
Product Attributes
| Bolt Length | 12.00 in. |
| Brand | Euclid |
| Head Diameter | 0.75 in. |
| Head Height | 0.4375 in. |
| Hex | 0.75 in. |
| Includes | Nut, Spring Center Bolt |
| Minimum Thread Length | 9.50 in. |
| Notes | Spring Center Bolt, Head Height 7/16 |
| Suspension Model | Reyco/Granning 21B, 73, 74B, 79KB, 83, 101, 101A, 102, 102AR / Spicer 36 |
| Thread Diameter | 0.500 in. |
| Threads Per Inch | 20 |
EUCLID E-3197 Cross References
EUCLID E-3197 Customer Reviews
No reviews yet
Be the first to review this product!
EUCLID E-3197 Manufacturer Information
Euclid® is a world leader in the production of precision-engineered replacement parts for buses, trailers, as well as light-, medium- and heavy-duty trucks. This brand takes great pride in its products that meet and even exceed O.E.M. quality standards. Officially a part of Meritor since January 1999, Euclid remains the same despite all the changes the company has been through. When customers receive Euclid products, they know they are getting far more than ordinary replacement parts. Instead, they are getting the best replacement parts made today from a company they can trust. Euclid is a company that's continuously improving with technology to do a job the right way because it is the only way it knows how.
