EUCLID part description

Body Diameter 19.86 mm
Body Length 26.9 mm
Grade 8
Head Diameter 33.3 mm
Head Style Round
Head Thickness 7.9 mm
Length from Under Head 74.7mm
Metric Thread Size 3/4-16 UNF-2A
OEM Meritor 09-001614
Serration Serrated
Serration Diameter 20.57 mm
Serration Length 12.7 mm
Thread Diameter 0.75 in.
Thread Direction RH
Thread Length 44.5 mm
Threads per Inch 16
Type Headed
VMRS Code 018-003-009

Product Description

STUD

Product Attributes

Body Diameter 19.86 mm
Body Length 26.9 mm
Brand Euclid
Grade 8
Head Diameter 33.3 mm
Head Style Round
Head Thickness 7.9 mm
Length From Under Head 74.7mm
Metric Thread Size 3/4-16 UNF-2A
OEM Meritor 09-001614
Pallet Quantity 550
Serration Serrated
Serration Diameter 20.57 mm
Serration Length 12.7 mm
Thread Diameter 0.75 in.
Thread Direction RH
Thread Length 44.5 mm
Threads Per Inch 16
Type Headed
Weight .58

EUCLID E11666R Cross Reference

We have 1 alternatives for the E11666R by EUCLID:

Euclid® is a world leader in the production of precision-engineered replacement parts for buses, trailers, as well as light-, medium- and heavy-duty trucks. This brand takes great pride in its products that meet and even exceed O.E.M. quality standards. Officially a part of Meritor since January 1999, Euclid remains the same despite all the changes the company has been through. When customers receive Euclid products, they know they are getting far more than ordinary replacement parts. Instead, they are getting the best replacement parts made today from a company they can trust. Euclid is a company that's continuously improving with technology to do a job the right way because it is the only way it knows how.
