HALDEX part description

Product Description

DRYest™ Air Dryer, 12V, Kit

Features & Benefits

  • Made with a multi-treatment cartridge that employs five stages of cleaning to ensure dry system air
  • Offers ease of installation anywhere as it comes in an extra compact size
  • An extended service air dryer specifically designed for system purge application
  • Designed with a built-in heater to prevent dryer freezing and damage
  • Built to offer integrated turbo protection
  • Has an integrated muffler for superior quiet operation

Haldex DRYest™ Air Brake Dryer

Prevent air-line freeze-ups with the Haldex DRYest™ air brake dryer. Manufactured by a brand with more than 100 years of engineering expertise, this air dryer ensures only clean, dry air is being supplied to the air brake system as it helps filter most liquid and water vapor from the compressor discharge air.

Product Attributes

Dessicant Cartridge Weight 3.5 lbs.
Drying Capacity 5.8 SCF
Drying Stages 5
Freight Class 70
Governor Cut-Out 125 ± 5 PSI
Governor Included No
Heater Included Yes
Heater Voltage 12V
Maximum Inlet Airflow 35 SCFM
Maximum Working Pressure 170 PSI
Maximum Working Temperature 170°F
Minimum Working Temperature -40°F
Mounting Bracket Included Yes
New Or Remanufactured New
Notes For use With External Purge Tank
Pressure Drop 35 SCFM/175 PSI = 3 PSI
Regeneration Valve System Purge Drain Silencer
Safety Relief Pressure 150 PSI
Series DRYest™
System Regeneration No
Turbo Protection 35 PSI Inlet Required
Wattage 90 Watts

Additional Information

Country of Origin (Primary) MX
Harmonized Tariff Code (Schedule B) 8421398015
Harmonized Tariff Code (HTS) 8421398015
Remanufactured Part N
Warranty Distance 100000
Warranty Distance UOM MI
Warranty Special See Haldex Aftermarket Product warranty Policy (L20221W).pdf
Warranty Time 12
Warranty Time UOM MO
UPC 00767653283081
VMRS Code 013010252

Part Interchanges

Haldex® is a Sweden-based manufacturer specializing in brake and air suspension systems for heavy duty vehicles. Its product line consists of brake components for wheel ends, including disc brakes, brake adjusters, and actuators. It also offers air control products such as compressed air dryers, valves, ABS, and EBS. All these Haldex products are designed with safety and efficient operation in mind, cutting down on potential hazards and maintenance costs in the long run. Today, Haldex runs manufacturing and R&D facilities in 19 countries across four continents. It is dedicated to producing high-quality brake and suspension parts for its customers all around the world as well as developing new technologies for the future.

HALDEX DA35110 Cross Reference

We have 2 alternatives for the DA35110 by HALDEX:
