GATES TR22386 Part Description
Manufacturer
Product Description
Green Stripe Truck & Bus Series V-Belt
Application Summary
1991-1989 UD (Nissan), UD1100, Nissan FD35T Diesel, Fan & P.S.
Features & Benefits
- Molded notches reduce bending stress, especially on small diameter pulleys, while dissipating heat
- High modulus, high strength tensile cord
- Oil and heat-resistant construction throughout
- Meets SAE J636b and SAE J637 specifications
- Meets RMA oil and heat resistant standards and static conductivity requirements
- NOTE: Some sizes available as Gates PowerBand joined V-belts
GATES TR22386 Specifications
Product Attributes
| Type | Truck & Bus V-Belt |
| Cross Section Designation | RA |
| Angle | 40 |
| Strand Quantity | 1 |
| Top Width | .594 in |
| Outside Circumference | 39.11 in |
| Effective Length | 38.53 in |
| Construction | Notched |
| Notched | Yes |
| Belt Material | EPDM |
| Cord Material | Polyester |
| Top Width | 15 mm |
| Outside Circumference | 993 mm |
| Effective Length | 979 mm |
Additional Information
| Harmonized Tariff Code (Schedule B) | 4010323000 |
| Country of Origin (Primary) | US |
| UPC | 00072053277920 |
| VMRS Code | 065005003 |
| UNSPSC | 26111801 |
GATES TR22386 Part Interchanges
| Brand | Part Number |
|---|---|
| Carlisle | CR400356 |
| Mopar | BH-58 |
| Motorcraft | JE-387, JE-392, JF-393, JN-387 |
| Sierra | 18-22385 |
| White | 027136084, 049041666, 518245, 697689 |
| ACDelco | T22386 |
| Dayco | 22385, 420344, 422645, 429037, 434553, 45817, 51318, 54911, 58946, 719M, 77 |
| Carquest | TR22386 |
| Allis Chalmers | 4345068, 4351234, 4616599, DE51234 |
| Bando | 5375, B5375 |
| Bendix-Westinghouse | 237020 |
| Caterpillar | 1D6178, 3134, 351923, 351924 |
| Clark Equipment | 669976 |
| Climax Engr | 41187 |
| Continental Belt | 22385MK |
| Cummins | 178541, 3040348, 69403, S3162 |
| Datsun/Nissan | 1192005E05, 1192005E10, 1192005E15, 197820984 |
| Dresser | RD50739 |
| Fiat | 841045, 86307 |
| First Products | 22-385 |
| Fleetrite | ZAH22385 |
| General Motors | 1340658, 2193426, 601518, 609279, 9030292, 9042558 |
| Renault | 5526243, 6002333, 8518909 |
| Ford | AE 1607, C6TA 8620 G, C6TZ 8620 G, C9PZ 8620 DY, C9PZ 8620 GR, E93A 8620 C, G83A 8620 |
| Toyota | 141040201, 9933300980 |
| International Harvester (IHC) | 11030R, 205987R1, 261179C1, 285916C1, 286796C1, 56788HA, 752420C1 |
| Massey Ferguson | 852175M1 |
| Towmotor | 351925, B3134, F162K208 |
| Koehring | 11653 |
| Komatsu | 0412001713, 0412021739, 0412011713 |
| Kysor | 300252, B1764540 |
| Mitsuboshi | MF8375, RECMF8375, REMF8375 |
| Onan | 5118 |
| Ready Power | 10780 |
| Steiger Tractor | 061473, 061473A |
| Thermo-King | 2020B40H33, 2020B40H75, 2028B89H41, 780231, 78231 |
| UD Trucks | 1195001D00 |
| Versatile | 22573 |
| Waukesha | 78784 |
| Mack | 88GB330P160 |
| Palmer | 7513 |
| Goodyear | 22390 |
| Volvo GM Heavy Truck | V1091018 |
| NAPA Belts/Hose | 25-22386 |
| Durkee-Atwood | 22-392 |
| Eaton, Yale & Towne | H2551 |
| Globe Lifeline | 1659 |
| Gray Marine | 67854 |
| Lift Parts | 1561190, 1561200, 1568060 |
| MBL Three Stars | 22385 |
| NAPA | 25-09800 |
| Service King | 115C, 6339 |
| Teledyne Continental | F169K208, F400T232, Y69K221, Y91K209 |
| Teledyne Wisconsin | MH64 |
| Thew | D57772 |
| Perkins | 0070083 |
| <Unknown> | 1CW103, 1LA0510, 22393, 303987R2, 652447, 70698556, 7397, 863607, 986796, 9B3134, F162K2D8, MC862339, UE2803, UE3790 |
| Metric | 15A0980, 17A0975 |
GATES TR22386 Fits Vehicles
- Cunningham Series V-6 (1925-1927)
- Cunningham Series V-5 (1924)
- Cunningham Model S (1916)
- Cunningham Series V-4 (1922-1923)
- Cunningham Series V-7 (1928-1929)
- Cunningham Series V (1917-1921)
- DAF 55 (1967)
- DAF American (1965-1967)
- DAF Daffodil (1962-1964)
- DAF 600 (1959, 1961-1964)
- DAF 44 (1967)
- DAF 750 (1962-1964)
- Cunningham Continental (1953-1954)
- Essex Challenger (1929-1930)
- Essex Super Six (1928)
- DeTomaso Pantera (1971)
- DeTomaso Mangusta (1967-1970)
- Chevrolet Universal Truck (1930)
- Moon Model 6-72 (1928-1929)
- Chevrolet Confederate (1932)
- Chevrolet Standard (1935-1936)
- UD 1100 (1989-1991)
- Chevrolet Master (1934-1936)
GATES TR22386 Cross References
We have 1 alternatives for the TR22386 by GATES:
