Gates H24100-06F - RFS Red Fire Suppressant Hose
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
GATES part description
Product Description
RFS Red Fire Suppressant Hose
Features & Benefits
- For use with MegaCrimp Couplings [G25 Series] and Power Crimp Couplings
- The red cover is for easy visual identification in these applications
- Meets performance requirements of SAE 100R1 and meets Flame Resistance Acceptance Designation MSHA 2G
- Temperature Range: -40 Deg. F to +212 Deg. F (-40 Deg. C to +100 Deg. C)
Product Attributes
| Product Type | RFS Red Fire Suppressant Hose |
| Industrial Description | 6RFSXREEL |
| Type | Hydraulic Hose |
| Hose Pressure Description | Low Pressure |
| Maximum Working Pressure | 2250 PS |
| Burst Pressure | 9000 PS |
| Temperature Rating | -40 Deg. F to +212 Deg. F (-40 Deg. C to +100 Deg. C) |
| Length | 300 FT |
| Dash Size | 6 |
| Inside Diameter | .375 IN |
| Outside Diameter | .68 IN |
| Bend Radius | 5 IN |
| Tube Description | Black, Oil-Resistant, Synthetic Rubber |
| Hose Material | Nitrile - Type C |
| Reinforcement Material | One Braid, High-Tensile Steel Wire |
| Cover Material | Modified Nitrile - Type C2 |
| Cover Type | Type C2 - Flame, Oil & Abrasion Resistant |
| Cover Color | Red |
| Coupling Recommendation | MegaCrimp |
| SAE Standard | 100R1 |
| EN Standard | N/A |
| ISO Standard | N/A |
Additional Information
| Harmonized Tariff Code (Schedule B) | 4009210000 |
| Country of Origin (Primary) | US |
| UPC | 00072053671322 |
| VMRS Code | 059032029 |
| UNSPSC | 40142020 |
