(888) 312-8812 Login SignupGATES G20315-2016 Code 61 O-Ring Flange - 90 Bent Tube (GlobalSpiral)
Tap to view 3 more
$15149
Limited availability at this price!
In Stock
Get it by Friday, Jul 3
GATES G20315-2016 Part Description
Manufacturer
Product Description
Code 61 O-Ring Flange - 90 Bent Tube (GlobalSpiral)
Features & Benefits
- "Bite-the-wire" crimp for improved coupling retention
- “Bite-the-wire” crimp for improved coupling retention
- Tested to an industry-leading 1,000,000 impulse cycles
- +250degF temperature capability for longer assembly life
- +250°F temperature capability for longer assembly life
- +250?F temperature capability for longer assembly life
- +250˚F temperature capability for longer assembly life
- Environmentally-friendly TuffCoat plating for 347 percent better corrosion resistance than the SAE Standard
GATES G20315-2016 Specifications
Product Attributes
| Coupling Description | GlobalSpiral Code 61 O-Ring Flange - 90 Bent Tube |
| Industrial Description | 20GS-16FL90M |
| Inside Diameter | 1.25 IN |
| Hydraulic Hose Recommendation | All Gates MegaSys Four and Six-Spiral Wire Hydraulic Hose Up to 8,000 psi |
| Maximum Working Pressure | 5000 PS |
| Flange Thickness | .32 in |
| Flange Diameter | 1.75 IN |
| Drop Length | 2.76 IN |
| Cut-Off Length | 3.5 IN |
| Length | 6.3 IN |
| Inside Diameter | 31.8 MM |
| Flange Thickness | 8.1 MM |
| Flange Diameter | 44.5 MM |
| Drop Length | 70.1 MM |
| Cut-Off Length | 88.9 MM |
| Length | 160 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8412909015 |
| Country of Origin (Primary) | US |
| Stock Status | S |
| UPC | 00072053474657 |
| VMRS Code | 059032012 |
| UNSPSC | 31163000 |
GATES G20315-2016 Cross References
| Brand | Part Number |
|---|---|
| Aeroquip | 4S16FLB20 |
| Dayco | 102171 |
| Goodyear | 28350-2016, S4-FL90-2016 |
| N/A | 04031011, M23391-20-16, M83391-20-16 |
| NAPA | G20315-2016 |
| Parker | 11971-16-20, 1B16FLB20 |
