GATES G20180-1012 Part Description
Manufacturer
Product Description
Female JIC 37 Flare Swivel - 90 Bent Tube (GlobalSpiral)
Features & Benefits
- "Bite-the-wire" crimp for improved coupling retention
- “Bite-the-wire” crimp for improved coupling retention
- Tested to an industry-leading 1,000,000 impulse cycles
- +250 Deg. F temperature capability for longer assembly life
- Environmentally-friendly TuffCoat plating for 347 percent better corrosion resistance than the SAE Standard
GATES G20180-1012 Specifications
Product Attributes
| Coupling Description | GlobalSpiral Female JIC 37 Flare Swivel - 90 Bent Tube |
| Industrial Description | 10GS-12FJX90M |
| Thread Size | 1 1/16-12 |
| Inside Diameter | .625 IN |
| Hydraulic Hose Recommendation | All Gates MegaSys Four and Six-Spiral Wire Hydraulic Hose Up to 8,000 psi |
| Nut Hex Size | 1.25 IN |
| Drop Length | 2.28 IN |
| Cut-Off Length | 2.78 IN |
| Length | 4.76 IN |
| Inside Diameter | 15.9 MM |
| Drop Length | 57.9 MM |
| Cut-Off Length | 70.7 MM |
| Length | 120.9 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8412909015 |
| Country of Origin (Primary) | US |
| Stock Status | S |
| UPC | 00072053441383 |
| VMRS Code | 059032012 |
| UNSPSC | 31163000 |
GATES G20180-1012 Cross References
| Brand | Part Number |
|---|---|
| Aeroquip | 1BA12FJB10, 4SA12FJB10 |
| Goodyear | 28425-1012, 29425-1012, 29440-1012, S4-JCFX90-1012 |
| N/A | 04030769 |
| NAPA | G20180-1012 |
