GATES C109 Part Description
Manufacturer
Product Description
Hi-Power II Classical Section Wrapped V-Belt
Application Summary
John Deere, 9500, John Deere 6-Cyl. 464 Diesel, Chopper - Windrow or Forward Position
Features & Benefits
- Smoother running with less slip and wear for excellent belt service life and reduced pulley wear
- High-quality rubber compound protects the belt against heat, ozone and sunlight
- Proprietary Flex-Weave cover is a patented fabric construction, providing extended protection to the belt core from oil, contaminants and heat for longer belt life
- Flex-bonded cords strongly adhere to the body of the belt, resulting in equal load distribution and absorption of bending stress, fatigue and shock loads without cord deterioration
- Meets RMA oil and heat resistant standards and static conductivity requirements
- Temperature Range: -22 Deg. F to +140 Deg. F (-30 Deg. C to +60 Deg. C)
- NOTE: Available in A, B, C, D and E cross-sections as well as Hi-Power II PowerBand V-belts
GATES C109 Specifications
Product Attributes
| Type | Classical Section Wrapped V-Belt |
| Cross Section Designation | C |
| Strand Quantity | 1 |
| Top Width | .88 in |
| Outside Circumference | 113 in |
| Construction | Wrapped |
| Notched | No |
| Belt Material | EPDM |
| Cord Material | Polyester |
| Top Width | 22 mm |
| Outside Circumference | 2870 mm |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 4010391000 |
| Stock Status | S |
| UPC | 00072053019933 |
| VMRS Code | 065005003 |
| UNSPSC | 26111801 |
GATES C109 Cross References
| Brand | Part Number |
|---|---|
| 90046109 | |
| <Unknown> | 1056877M1 |
| ACDelco | IC109 |
| Allis Chalmers | 538180, 70538180 |
| Black Welders | V5113 |
| Browning Manufacturing | C109 |
| CARQUEST | C109 |
| CONTINENTAL AG | C109 |
| Dayco | CP109 |
| GOODYEAR BELTS | C109 |
| Goodyear | 78109, C109 |
| Grainger | 4FH86 |
| Hesston | 254516, 855403 |
| International Harvester (IHC) | 607344R1, 666390R1 |
| John Deere | P40023H, P47885 |
| Kubota | 70706-34710 |
| Lockwood | 25021125 |
| Mac-Don | 63889 |
| Massey Ferguson | 222666M1 |
| Metric | 22C2870 |
| Mitsuboshi | LC112 |
| N/A | 41010879, C109, RC109 |
| NAPA | C109 |
| NAPA Belts/Hose | C109 |
| New Holland | 181068, 86514497 |
| PIX | A-C109, A-W9811190 |
| Reliance Electric | 107123 |
| Timken | C109, CP109 |
| Versatile | 360722V1 |
| White | 9811190, W9811190 |
