GATES 9565 Automotive XL High Capacity V-Belt

★★★★★ (0) Write a Review
9565 by GATES - Automotive XL High Capacity V-Belt
GATES
Tap to view 1 more
SHIPS TODAY

MSRP: $32.57

$25.49

Save $7.08

Limited availability at this price!

In Stock

Get it by Tuesday, Jan 27
No Hassle Return Policy Details
Free Economy shipping on orders over $499 details
Orders placed before 2pm EST will ship same day

GATES 9565 Part Description

Manufacturer

GATES

Product Description

Automotive XL High Capacity V-Belt

Application Summary

1994-1990 International/Navistar, 3700, International/Navistar V-8 7.3 L Diesel, Air Brake Compr.

Features & Benefits

  • Fiber-loaded rubber stock adds flexibility along the length of the belt and provides greater lateral stability in the pulley
  • Form-ground to ensure precise top width and sidewall dimensional control for proper fit to the pulley
  • Thermally-active tensile cords for maintenance-free performance when properly installed and tensioned
  • Resists oil, heat, ozone, weather and aging for improved belt life
  • Meets or exceeds SAE J636C specifications

GATES 9565 Specifications

Product Attributes

Type High Capacity V-Belt (Standard)
Cross Section Designation HC50
Angle 36
Strand Quantity 1
Top Width .47 in
Outside Circumference 57.1 in
Effective Length 56.5 in
Construction Notched
Notched Yes
Belt Material EPDM
Cord Material Polyester
Top Width 12 mm
Outside Circumference 1450 mm
Effective Length 1435 mm

Additional Information

Country of Origin (Primary) US
Harmonized Tariff Code (Schedule B) 4010323000
UPC 00072053312423
VMRS Code 065005003
UNSPSC 26111801

GATES 9565 Cross References

BrandPart Number
87019565
<Unknown>4167818, 5000552493, 505042C91, 56693X500, 73073004, 73073005, 74029380, 8500486, 9691356135, AT31560
ACDelco9565HD, 17565
AGCO71372945, 71372945A
Alliance Truck PartsGT17565E, GT17565, GT17566E, GT9565
Allis Chalmers254350
Armormark17565
Atlas (Canada)A16568
Bando3555, 4565, B3555
Beck/Arnley141-1337, 145-041430
CONTINENTAL AG17565
Cadna Belts and Hose17565
Canadian Tire13A1435, 14-0782-6
Carquest9565HD, 9565
Caterpillar4N7610
ContiTech11-5X685, 13X1450
Continental Belt17565MK
Cummins202045, 3004309
Datsun/Nissan1192010G01, 1192010G02
Dayco13V1435, 17565, 17565DR, 420469, 420874, 420974, 421265, 421272, 421557, 421596, 422954, 423029, 423050, 423816, 424485, 425090, 426491, 427128, 427427, 427428, 427526, 427676, 427781, 427798, 427923, 430026, 432678, 432982, 433021, 434265, 434381, 434538, 434703, 435278, 435594, 44720, 54424, 55590, 58710, 58771
Deutz-allis70254350, 70254351
Dresser686522C1
Eaton, Yale & TowneAZ7612
First Products17-565
FordC8HA 8620 J, D2AE 8620 BLA, D2AE 8620 FA, E0TA 8A615 JA, E0TE 8A615 JA, E3AZ 8620 D, E9HT 8A615 AA, F1HZ 8620 N
Freightliner Trucks2310001082
GOODYEAR BELTS17565
General Motors2443474, 2443475, 718086, 9433918
Goodyear17565
HD Value17565HDV
International Harvester (IHC)339700C2, 406097R1, 505041C91
John DeereT32510
Lift Parts00015617565
Mack88GB354P30B
Massey Ferguson1052007M1, 3595070, 3595070M91
Metric12.5X1430LA, 13A1440
MitsuboshiMF6555, RECMF6555, REMF6555
MoparB0017570
MotorcraftJC-567-L, JC-568
NAPA25-14355, 401-9565
NAPA Belts/Hose25-9565HD, 25-9565
New Holland9636395
Parts Master17565
Perkins2612438, 2614B063, 2614B163
UD Trucks1193005001, 193005D01
Volvo Cars967140, 967198, 967270, 978799, 978800, 978801
Volvo GM Heavy TruckV1090836, V1090990
Volvo Penta969135

GATES 9565 Fits Vehicles

  • International 4700LP (1994)
  • Freightliner FLB (1994, 1996)
  • Freightliner FLA086 (1989-1994)
  • Western Star 4800 (1998)
  • Peterbilt 379 (1987-1993)
  • Peterbilt 362 (1988-1991, 1995-1997)
  • Peterbilt 359 (1984-1987)
  • Peterbilt 375 (1987-1993)
  • International 4700 (1994)
  • International 4600 (1991-1994)
  • International 4600LP (1991-1994)
  • International 3700 (1990-1994)
  • Volvo 780 (1987, 1990)
  • Volvo 760 (1986-1987, 1990)
  • Ford F-800 (1991)
  • Ford CF7000 (1991-1993)
  • Ford F-600 (1991-1993)
  • UD 1300 (1993)
  • Ford C8000 (1990)
  • Ford CT8000 (1990)
  • Ford F-700 (1991-1993)
  • UD 1400 (1994-1995)
  • Ford F-700 LPO (1991-1993)
  • Ford F-600 LPO (1991-1993)
  • White WCA (1988)
  • White WIA (1988)
  • White/GMC WIA (1988-1993)
  • White/GMC WCA (1988-1993)
  • Ford B-700 (1984-1988, 1990-1993)
  • Ford B-600 (1984-1988, 1990-1993)
  • Nissan 720 (1983-1986)
