GATES part description

Product Description

GTH High -Temp 1-Fiber Braid Hose - SAE 100R6

Features & Benefits

  • For use with MegaCrimp Couplings [G25 Series] and Power Crimp Couplings
  • Meets or exceeds requirements of SAE 100R6
  • Temperature Range: Hydraulic Oil Lines: -40 Deg. F to +275 Deg. F (-40 Deg. C to +135 Deg. C) constant; +300 Deg. F (+149 Deg. C) intermittent (up to 10 percent of operating time)

Product Attributes

Product Type GTH High-Temp 1-Fiber Braid Hose - SAE 100R6
Industrial Description 5GTHX50FT
Type Hydraulic Hose
Hose Pressure Description Low Pressure
Maximum Working Pressure 400 PS
Burst Pressure 1600 PS
Temperature Rating -40 Deg. F to +275 Deg. F (Constant) and +300 Deg. F (Intermittent)
Length 50 FT
9941 5
Inside Diameter .3125 IN
Outside Diameter .56 IN
9879 3
9835 28 INHG
Tube Description Black, Specially Compounded, Synthetic Rubber
Material Nitrile - Type C
Reinforcement Material One Fiber Braid
Cover Material Synthetic Rubber - Neoprene - Type A
Cover Type Type A - Oil & Abrasion Resistant
Cover Color Black
9856 MegaCrimp
9453 100R6
9954 N/A
9953 N/A

Additional Information

Harmonized Tariff Code (Schedule B) 4009310000
Country of Origin (Primary) IN
UPC 00072053078312
VMRS Code 059032029
UNSPSC 40142020
