GATES part description

Product Description

M2T MegaFlex 2-Wire Braid Hose - SAE 100R16

Features & Benefits

  • For use with GlobalSpiral Couplings [G20 Series], GlobalSpiral Plus Couplings [G22 Series], MegaCrimp Couplings [G25 Series], Stainless Steel Braid Couplings [G17 Series] and Stainless Steel Spiral Couplings [G18 Series]
  • Provides bend radius up to 1/3 of the SAE specification and greater flexibility for easier routing
  • Tested to industry-leading 600,000 impulse cycles
  • XtraTuff hose lasts up to 25 times longer than standard hose
  • MegaTuff hose lasts up to 300 times longer than standard hose during hose-to-hose and hose-to-metal abrasion tests per ISO 6945 and offers superior ozone and weathering resistance
  • Meets Flame Resistance Acceptance Designation MSHA 2G
  • Temperature Range: -40 Deg. F to +212 Deg. F (-40 Deg. C to +100 Deg. C)

Product Attributes

Product Type M2T MegaFlex 2-Wire Braid Hose - SAE 100R16
Industrial Description 8M2TX50FT
Type Hydraulic Hose
Hose Pressure Description High Pressure
Maximum Working Pressure 4300 PS
Burst Pressure 17200 PS
Temperature Rating -40 Deg. F to +212 Deg. F (-40 Deg. C to +100 Deg. C)
Length 50 FT
9941 8
Inside Diameter .5 IN
Outside Diameter .82 IN
9879 2.8 IN
Tube Description Black, Oil-Resistant, Synthetic Rubber
Hose Material Nitrile - Type C
Reinforcement Material Two Braids, High-Tensile Steel Wire
Cover Material Synthetic Rubber - Modified Nitrile - Type C2 - Color Coded Layline
Cover Type Type C2 - Flame, Oil, Abrasion & Weather Resistant
Cover Color Black
9856 GlobalSpiral, MegaCrimp, Stainless Steel B
9453 100R16
9954 857 2SC, 853 2SN
9953 11237 2SC R16, 1436 2SN R2

Additional Information

Harmonized Tariff Code (Schedule B) 4009210000
Country of Origin (Primary) MX
UPC 00072053229851
VMRS Code 059032029
UNSPSC 40142020
