(888) 312-8812 Login SignupGATES 70422 G3H High-Temp 2-Fiber Braid Hose - SAE 100R3
$31.37
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
GATES 70422 Part Description
Manufacturer
Product Description
G3H High-Temp 2-Fiber Braid Hose - SAE 100R3
Features & Benefits
- For use with GLX Couplings [G44 Series] and MegaCrimp Couplings [G25 Series]
- Meets or exceeds requirements of SAE 100R3
- Temperature Range: Hydraulic Oil Lines: -40 Deg. F to +275 Deg. F (-40 Deg. C to +135 Deg. C) constant; +300 Deg. F (+149 Deg. C) intermittent (up to 10 percent of operating time)
GATES 70422 Specifications
Product Attributes
| Product Type | G3H High-Temp 2-Fiber Braid Hose - SAE 100R3 |
| Industrial Description | 24G3HXCTN |
| Type | Hydraulic Hose |
| Hose Pressure Description | Medium Pressure |
| Maximum Working Pressure | 300 PS |
| Burst Pressure | 1200 PS |
| Temperature Rating | Oil Lines: -40 Deg. F to +275 Deg. F (Constant), up to +300 Deg. F (Intermittent) |
| Length | 131 FT |
| Dash Size | 24 |
| Inside Diameter | 1.5 IN |
| Outside Diameter | 1.94 IN |
| Bend Radius | 12 IN |
| Vacuum Rating | 10 INHG |
| Tube Description | Black, Synthetic Rubber |
| Hose Material | Nitrile - Type C |
| Reinforcement Material | Two Fiber Braids |
| Cover Material | Synthetic Rubber - Neoprene - Type A |
| Cover Type | Type A - Oil & Abrasion Resistant |
| Cover Color | Black |
| SAE Standard | 100R3 |
| EN Standard | N/A |
| ISO Standard | N/A |
Additional Information
| Harmonized Tariff Code (Schedule B) | 4009310000 |
| Country of Origin (Primary) | IN |
| Stock Status | N |
| UPC | 00072053832747 |
| VMRS Code | 059032029 |
| UNSPSC | 40142020 |
GATES 70422 Cross References
| Brand | Part Number |
|---|---|
| N/A | 04030236 |
| NAPA | 70422 |
