(888) 312-8812 Login SignupGATES 358560 Power Steering Pressure Line Hose Assembly
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
GATES 358560 Part Description
Manufacturer
Product Description
Power Steering Pressure Line Hose Assembly
Application Summary
1991-1987 Chevrolet, G Series Van, V-8 5.7 L, Pressure
Features & Benefits
- Extensive field examination and testing assure proper fit
- For passenger cars and light trucks
- General instructions are packed with every assembly
- Hoses and fittings are also available for tailor-made medium and heavy-duty truck applications
- Comes complete with factory-installed, pre-bent zinc-dichromate plated end fittings, bracketry, sensor ports, sheathing, bushings and grommets
- Exceeds SAE J2050 performance requirements. (Product Type 7741)
GATES 358560 Specifications
Product Attributes
| Grade Type | OE Performance |
| Length | 41 IN |
| End Diameter | 16 MM |
| End 1 Type | Male O-Ring |
| End 2 Type | Male O-Ring |
| Fully Assembled Pressure & Return Set | N/A |
| Switch Port Included | No |
| SAE Standard | Exceeds SAE J188 specifications |
| Tube Material | Zinc Single Wall Steel |
| Sleeve Material | Anti Corrosion Steel |
| Mounting Brackets Included | No |
| Sleeve Included | No |
| Washer(s) Included | No |
| Bushing Included | No |
| Mounts Included | No |
| Retainer Clips Included | N/A |
| Mounting Position | Pump to Rack/Gear Box |
Additional Information
| Country of Origin (Primary) | TW |
| Harmonized Tariff Code (Schedule B) | 4009320050 |
| UPC | 00072053423822 |
| VMRS Code | 065007006 |
| UNSPSC | 40141764 |
GATES 358560 Cross References
| Brand | Part Number |
|---|---|
| 77410856 | |
| ACDelco | 36-358560 |
| Autoline | 5-4134 |
| Carquest | 35856 |
| Continental Belt | 15558, 25558 |
| Edelmann | 70422, EP-422 |
| Everco | 3-474, 67474 |
| Four Seasons | 110205 |
| GSL | 2-9615 |
| General Motors | 26002377, 26002378 |
| MOOG Chassis Products | M-4134 |
| Moog | M-4124 |
| NAPA | 35856, 7-2103 |
| OMEGA ENVIRONMENTAL TECHNOLOGIES | 4134 |
| Omega | 4134 |
| PLEWS | 70422 |
| Republic | 13145 |
| SunSong | 3401500 |
GATES 358560 Fits Vehicles
- GMC G3500 (1987-1991)
- GMC G2500 (1987-1991)
- GMC G1500 (1987-1991)
- Chevrolet G30 (1987-1991)
- Chevrolet G20 (1987-1991)
- Chevrolet G10 (1987-1991)
