(888) 312-8812 Login SignupGATES 3530 Truflex FHP Low Horse-Power V-Belt
Tap to view 2 more
$2199
Limited availability at this price!
In Stock
Get it by Thursday, Jan 29
GATES 3530 Part Description
Manufacturer
Product Description
Truflex FHP Low Horse-Power V-Belt
Application Summary
Air-Electric, DS-25, , Belt
Features & Benefits
- Flex-bonded cords are strongly forged to the belt body, resulting in equal load distribution, resistance to fatigue and shock loads and the absorption of bending stress without cord deterioration
- Proprietary Flex-Weave cover is a patented fabric construction, providing extended protection to the belt core from oil, contaminants and heat for longer belt life
- Runs with smooth, quiet operation
- Meets RMA oil and heat-resistant standards and static conductivity requirements
- Available in 2L (0), 3L (1), 4L (2) and 5L (3) cross-sections
- Do not use on applications where FHP medium horsepower V-belts are recommended
GATES 3530 Specifications
Product Attributes
| Type | FHP Low Horse-Power V-Belt |
| Cross Section Designation | 5L |
| Angle | 36 |
| Strand Quantity | 1 |
| Top Width | .66 in |
| Outside Circumference | 53 in |
| Effective Length | 52.94 in |
| Construction | Wrapped |
| Notched | No |
| Belt Material | EPDM |
| Cord Material | Polyester |
| Top Width | 17 mm |
| Outside Circumference | 1346 mm |
| Effective Length | 1345 mm |
Additional Information
| Harmonized Tariff Code (Schedule B) | 4010323000 |
| Country of Origin (Primary) | MX |
| UPC | 00072053007343 |
| VMRS Code | 065005003 |
| UNSPSC | 26111801 |
GATES 3530 Cross References
| Brand | Part Number |
|---|---|
| <Unknown> | 105560, 113B8, 12286C, 15080, 15823, 2334, 2612, 31216531, 3912K, 5207, 5535, 5H57965A530, 7558, 9072, 9653, CC7882, KR20BC053, P82323, PS336, R10853, V107, V20218 |
| ACDelco | 5L530 |
| Air Electric | SD12 |
| American Lincoln | 20002147, 20002148 |
| BF Goodrich | 2530 |
| Browning Manufacturing | 2500, 3530 |
| CARQUEST | 3530 |
| CONTINENTAL AG | 5L530 |
| Climax Engr | 22CX50 |
| Dayco | 2M053, 5L530 |
| Food Machine | 1108562 |
| General Electric | K5705475AE22 |
| Gilmer | 4530 |
| Goodyear | 5L530, 75530, FB53 |
| Grainger | 5L530 |
| John Deere | LG58530, TY4441 |
| L Series | 5L530 |
| Metric | 16R1345 |
| Montgomery Ward | 504253 |
| Mopar | B5L-530 |
| NAPA Belts/Hose | 5L530 |
| Oregon | 75-853 |
| PIX | A-5L530 |
| Planet Products | 8275 |
| Power Lawnmower Part | 109-191 |
| Reliance Electric | 108109 |
| Rotary Lifts | 12-5180 |
| Sears | 5357H |
| Silver Streak | 75-853, DB5L530 |
| U.S. | 5204 |
| U.S. Government | 3030005284622, MS392435L530 |
| White | A1257 |
