GATES part description

Product Description

Green Stripe Heavy-Duty Vibraflex Hump Hose

Application Summary

1990-1980 Western Star, 4900 Series, Caterpillar 3406 Diesel, Upper

Features & Benefits

  • Oil and heat-resistant Nitrile tube
  • Oil, abrasion and heat-resistant Neoprene cover
  • Two-ply fabric reinforced
  • Exceeds SAE J20 (Class B Tube and Class C Cover)
  • Temperature Range: -40 Deg. F to +212 Deg. F (-40 Deg. C to +100 Deg. C)
  • Caution: Do not use for gasoline or diesel transfer applications

Product Attributes

Centerline Length 6 IN
End 1 Inside Diameter 2.5 in
End 2 Inside Diameter 2.5 in
2053 35 PS
Material EPDM
9839 Yes

Additional Information

Harmonized Tariff Code (Schedule B) 4009310000
Country of Origin (Primary) US
UPC 00072053062267
VMRS Code 042004014
UNSPSC 40142000

Part Interchanges

GATES 23550 Cross Reference

We have 1 alternatives for the 23550 by GATES:

Fits Vehicles

  • Western Star 6900 (1989-1990)
  • Western Star 4900 (1981-1990)
  • Western Star 4800 (1981-1990)
