(888) 312-8812 Login SignupGATES 20420 Premium Molded Coolant Hose
$2799
Limited availability at this price!
In Stock
Get it by Tuesday, Dec 16
GATES 20420 Part Description
Manufacturer
Product Description
Premium Molded Coolant Hose
Application Summary
International Harvester, 101, IH 6-Cyl. 220, Upper
Features & Benefits
- Specifically-engineered materials resist collapse under vacuum
- Specifically-engineered materials resist collapse under vacuum
- Engineered to resist electrochemical degradation, the leading cause of hose failure
- Pre-shaped to fit and to ensure perfectly sealed conditions
- EPDM tube; synthetic fiber knit reinforcement; heat-, ozone- and chemical coolant-resistant EPDM cover
- Meets requirements of SAE 20R4, class D2 and DIN 73411, class A (except for tolerances)
- Temperature Range: -40 Deg. F to +257 Deg. F (-40 Deg. C to +125 Deg. C)
- Note: Gates recommends replacing hose clamps each time a new coolant hose is installed
- Caution: Do not use for fuel or oil transfer applications
GATES 20420 Specifications
Product Attributes
| Centerline Length | 19.6 IN |
| Modular | No |
| Branch Quantity | 0 |
| Quick Connect Fitting Quantity | 0 |
| End 1 Inside Diameter | 2 in |
| End 2 Inside Diameter | 2 in |
| Contains Spring | Yes |
| Material | EPDM |
| Molded | Yes |
| Centerline Length | 498 MM |
| End 1 Inside Diameter | 51 MM |
| End 2 Inside Diameter | 51 MM |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 4009310000 |
| UPC | 00072053051131 |
| VMRS Code | 042004014 |
| UNSPSC | 40142000 |
GATES 20420 Part Interchanges
| Brand | Part Number |
|---|---|
| Mopar | BH-1055 |
| Motorcraft | KM-584 |
| White | 1716851 |
| ACDelco | 24010L |
| Carquest | 20420 |
| Allis Chalmers | 234634 |
| Caterpillar | 5M8214 |
| General Motors | 3768952, 3845431, 3833782, 518186, 523920, 530429 |
| Ford | AH 88277 A, B6S 8286 A, C8HA 8286 A, AH 8286 D, B5S 8286 D, C3TA 8260 E, C3TZ 8260 E |
| International Harvester (IHC) | 281625C1, 286750C1, 324890C1, 433663C1, 899348R1, 274714R1 |
| John Deere | U44437 |
| Reo Trucks | 646F2 |
| Ultralast | C0420 |
| Goodyear | 66695 |
| Durkee-Atwood | MR787 |
| <Unknown> | 853315005, V44437 |
| Continental Belt | E91654 |
| Duralast | F10958 |
GATES 20420 Fits Vehicles
- International Scout (1961-1970)
- Chevrolet C70 (1960-1961)
- Chevrolet C80 (1960-1965)
- Chevrolet C60 (1960-1965)
- Ford Thunderbird (1955-1957)
- Pontiac Super Chief (1957-1958)
- Pontiac Star Chief (1955-1958)
- Pontiac Chieftain (1955-1958)
- Pontiac Bonneville (1957-1958)
GATES 20420 Cross References
We have 1 alternatives for the 20420 by GATES:
