Gates 20417 - Premium Molded Coolant Hose
$3399
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
GATES part description
Product Description
Premium Molded Coolant Hose
Application Summary
1970-1968 Chevrolet, G Series Van, V-8 307, Lower
Features & Benefits
- Specifically-engineered materials resist collapse under vacuum
- Specifically-engineered materials resist collapse under vacuum
- Engineered to resist electrochemical degradation, the leading cause of hose failure
- Pre-shaped to fit and to ensure perfectly sealed conditions
- EPDM tube; synthetic fiber knit reinforcement; heat-, ozone- and chemical coolant-resistant EPDM cover
- Meets requirements of SAE 20R4, class D2 and DIN 73411, class A (except for tolerances)
- Temperature Range: -40 Deg. F to +257 Deg. F (-40 Deg. C to +125 Deg. C)
- Note: Gates recommends replacing hose clamps each time a new coolant hose is installed
- Caution: Do not use for fuel or oil transfer applications
Product Attributes
| Centerline Length | 19.7 IN |
| 9940 | No |
| Branch Quantity | 0 |
| 9845 | 0 |
| End 1 Inside Diameter | 1.75 in |
| End 2 Inside Diameter | 1.75 in |
| Contains Spring | No |
| Material | EPDM |
| 9839 | Yes |
| Centerline Length | 500 MM |
| End 1 Inside Diameter | 44 MM |
| End 2 Inside Diameter | 44 MM |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 4009310000 |
| UPC | 00072053051124 |
| VMRS Code | 042004014 |
| UNSPSC | 40142000 |
Part Interchanges
Fits Vehicles
- Chevrolet C60 (1960-1962)
- Chevrolet C50 (1960-1962)
- Chevrolet Truck (1960)
- Chevrolet C10 Panel (1960-1962)
- Chevrolet C30 Panel (1960-1962)
- GMC G35/G3500 Van (1970)
- Chevrolet C40 (1960-1962)
- Chevrolet G30 Van (1970)
- GMC G25/G2500 Van (1967-1970)
- GMC G15/G1500 Van (1967-1970)
- Chevrolet Suburban (1960-1962)
- Chevrolet K20 Pickup (1960-1962)
- Chevrolet K10 Pickup (1960-1962)
- Chevrolet G20 Van (1967-1970)
- Chevrolet G10 Van (1968-1970)
- Chevrolet C30 Pickup (1960-1962)
- Chevrolet C20 Pickup (1960-1962)
- Chevrolet C10 Pickup (1960-1962)
