(888) 312-8812 Login SignupGATES 1170 Truflex FHP Low Horse-Power V-Belt
Tap to view 2 more
$1099
Limited availability at this price!
In Stock
Get it by Thursday, Jul 30
GATES 1170 Part Description
Manufacturer
Product Description
Truflex FHP Low Horse-Power V-Belt
Application Summary
Brennan, IMP, Gas, Gen.
Features & Benefits
- Flex-bonded cords are strongly forged to the belt body, resulting in equal load distribution, resistance to fatigue and shock loads and the absorption of bending stress without cord deterioration
- Proprietary Flex-Weave cover is a patented fabric construction, providing extended protection to the belt core from oil, contaminants and heat for longer belt life
- Runs with smooth, quiet operation
- Meets RMA oil and heat-resistant standards and static conductivity requirements
- Available in 2L (0), 3L (1), 4L (2) and 5L (3) cross-sections
- Do not use on applications where FHP medium horsepower V-belts are recommended
GATES 1170 Specifications
Product Attributes
| Type | FHP Low Horse-Power V-Belt |
| Cross Section Designation | 3L |
| Angle | 36 |
| Strand Quantity | 1 |
| Top Width | .38 in |
| Outside Circumference | 17 in |
| Effective Length | 16.68 in |
| Construction | Wrapped |
| Notched | No |
| Belt Material | EPDM |
| Cord Material | Polyester |
| Top Width | 10 mm |
| Outside Circumference | 432 mm |
| Effective Length | 424 mm |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 4010391000 |
| Stock Status | S |
| UPC | 00072053000917 |
| VMRS Code | 065005003 |
| UNSPSC | 26111801 |
GATES 1170 Cross References
| Brand | Part Number |
|---|---|
| <Unknown> | 14913, 271227P, 40448, D14913, KK5705475AR1, SP3 |
| ACDelco | 3L170 |
| Apex Hose/Spec | 47187 |
| BF Goodrich | 0170 |
| Browning Manufacturing | 0155 |
| CARQUEST | 1170 |
| CONTINENTAL AG | 3L170 |
| Dayco | 0M017, 3L170 |
| Dumore Co | R4290017 |
| GOODYEAR BELTS | 3L170 |
| General Electric | K5705475AF1 |
| Gilmer | 2170 |
| Goodyear | 3L170, 73170, FO17 |
| Grainger | 3L170 |
| Kelvinator | 1030762 |
| L Series | 3L170 |
| Metric | 9R430 |
| Mopar | B3L-170 |
| NAPA Belts/Hose | 3L170, 1170 |
| Oregon | 75-617 |
| Power Lawnmower Part | 109-003 |
| Reliance Electric | 108152 |
| Rotary Lifts | 12-5000 |
| Silver Streak | 75-617, DB3L170 |
| Stanley Vemco | 210145 |
| Sunbeam | 4920568 |
| Toro | 27175, 31183 |
| U.S. | 8306 |
| U.S. Electric Motor | 37276A |
| White | 33R84 |
| X Series | 6X170 |
