MONROE 5630 OESpectrum Rear Suspension Shock Absorber

★★★★★ (0)
Monroe 5630 Suspension Shock Absorber OESpectrum Rear Suspension Shock Absorber
MONROE
Tap to view 11 more
Monroe 5630 Suspension Shock Absorber OESpectrum Rear Suspension Shock Absorber

MSRP: $126.75

$73.99

Save $52.76

Limited availability at this price!

In Stock

Get as soon as Friday, Nov 20
30-day Return Policy On eligible items Details
Free Ground shipping on orders over $499 details

MONROE 5630 Part Description

Manufacturer

MONROE

Product Description

OESpectrum Rear Suspension Shock Absorber

Features & Benefits

  • REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
  • DURABLE CONSTRUCTION -- Piston rod and reserve tube deliver added strength and resist deformation under demanding driving conditions
  • EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
  • EXCEPTIONAL HANDLING -- Consistent damping force in compression and rebound delivers better performance and handling in severe driving conditions
  • CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
  • CONTROL AND DURABILITY -- PTFE-banded piston, pressure tube and precision roll-close operation provide consistent sealing and structural strength for better control and long-term durability
  • CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
  • REDUCED NOISE, VIBRATION AND HARSHNESS -- Application-specific valving helps dampen road conditions while isolating impact-related noise, vibration and harshness
  • IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
  • CONSISTENT PERFORMANCE -- Nitrogen charge minimizes aeration and shock fade to keep damping consistent, reduce bounce and maintain tiretoroad contact for better handling in demanding conditions
  • BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
  • BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee

MONROE 5630 Specifications

Product Attributes

Compressed Length17.12 IN
Compressed Length434.8 MM
Extended Length26.38 in
Extended Length670.1 MM
Travel Length9.26 in
Travel Length235.2 MM
Lower Mount TypeSpecial Mount
Lower Mount TypeLoop (Eyelet) Bushing and Sleeve
Lower Mount CodeSPEC
Upper Mount TypeLoop Bushing and Sleeve Mount - 1/2" Sleeve ID X 38.1MM Sleeve OAL
Upper Mount CodeLS38
Shock Absorber Rod End Measuring PointCenter of Loop
Gas ChargedYes
Mounting Hardware IncludedYes
Parts Pack(s)None
Body ColorBlack
Cylinder ColorBlack
ColorBlack
Cylinder FinishPainted
Dust Shield IncludedNo
Includes Bump StopNo
Internal Rebound BumperNo
Hydraulic LockoutNo
Grade TypePremium
Active or Passive SuspensionPassive
Adjustable CompressionNo
Adjustable ReboundNo
Adjustable Ride HeightNo
Part DescriptionShock Absorber

Additional Information

MSDS Sheet Number01170
Country of Origin (Primary)CN
Canadian Harmonizing Tariff Code8708803000
Harmonized Tariff Code (Schedule B)8708800050
Harmonized Tariff Code (HTS)8708801600
UPC00048598082237
VMRS Code016008003
UNSPSC25172011

MONROE 5630 Cross References

BrandPart Number
5630ST, GB5Z17682CAPTM
AUTOZONETS32-32722B
AutoZoneTS3232722B
Autopart International2701603091
DuralastTS3232722B
FCS346017, 346964
FCS AUTO PARTS346017
FordBE8Z18124A, BE8Z18124B, BE8Z18124C, BE8Z18124D, BE8Z18125A, BE8Z18125B, D2BZ18124A, D2BZ18124B, D2BZ18125A, D2BZ18125B
GABRIEL70052, G51295
KYB553379, 348018, 3438002
KYB AMERICA LLC.348018, 553379
MasterPro Shocks and StrutsFD179
MazdaD04A2870XE, D65162620A, D65163620A, DR612870X, DR6134700B, DR6134700C, DR6134900B, DR6134900C
Monroe Shocks & Struts210068
NAPA Shocks5630, NS5630
OEMD2BZ18125B, DR612870X, D65162620A, D04A2870XE, BE8Z18125A, D65163620A, D2BZ18125A, BE8Z18125B
PM AutoPM6001421
PRT370716
SENSEN3212-0366
Sachs316896
Sensen32120366
TRQSBA70242
TRWJGT5460S
Top Quality785630
UNITY AUTOMOTIVE2-252140-001, 252140
Unity252140

MONROE 5630 Fits Vehicles

  • Ford Fiesta (2011-2019)
  • Ford Figo (2016-2020)
  • Mazda 2 (2011-2014)
