Name: Weatherhead 4225-54003 Synflex 4225 Series Thermoplastic Specialty Hose and Tubing
SKU: 422554003
Price: 1815.0 USD
Availability: InStock

WEATHERHEAD part description

California Proposition 65 Warning

WARNING: This product can expose you to chemical which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov. (Read more)

Product Name	Eaton Synflex 4225 Series Thermoplastic Specialty Hose and Tubing
Construction	Extruded
Tube material	Nylon
Color	Black
Conductivity	Non-Conductive
Dash size	-5
Working temperature - min	-40 F
Working pressure	250 Psi
Outside diameter	.312 IN
Reinforcement material	Synthetic fiber
Inside diameter	.232 IN
Cover material	Vinyl Nitrile
Tube wall thickness	.04 IN
Bend radius - min	1.13 IN
Burst pressure	1000 Psi
Application	Low pressure hydraulic, chemical transfer service, pneumatic systems.
Working temperature - max	200 F

Officially acquired by Eaton in 2002, Weatherhead® is one of the industry’s biggest suppliers of hydraulic hose, hose ends, tube fittings, couplings, assembly equipment, and support accessories. Weatherhead crafts top-products that are widely used in mining, agriculture, construction, truck, and bus applications. Eaton delivers Weatherhead thermoplastic tubing in different sizes—from 1/8 to 1 inch—designed for use in air tools, robotics, beverage dispensing as well as air and water supply. Driven by the company’s goal to offer unique solutions to a wide range of markets that enable businesses to be at the forefront of change, Weatherhead remains the truck industry’s leading source of premium-quality hoses, fittings, and adapters for your fleet’s hose and fittings needs
