WABCO 9324000240 - Air Brake Dryer - Single Chamber Air Dryer+Unloader
$2,43999
MSRP: $4,475.55
Save: $2,035.56
Limited Availability
. Learn more
WABCO part description
Air Brake Dryer - Single Chamber Air Dryer+Unloader
Product Attributes
| Port Thread 4/2 | 1/4" - 18 NPTF |
| Operational Range | 1.5 bar |
| Port Thread 4/23 | 1/4" - 18 NPTF |
| Max. operating pressure | 13.0 bar |
| Cut-Out Pressure | 12.0 bar |
| Operating Pressure | 13.0 bar |
| Opening Pressure | 14.50 bar |
| Size | 272 x 192 x 185 |
| Weight | 8.8538 |
| Calculated Volume (dm³) | 9.661 |
| Temperature Range | -40°C to +65°C |
| Exhaust | JED-463-1 |
| Cartridge Type | Desiccant Cartrige |
| Voltage | 24 V |
| Port thread 11 | M22 x 1.5 |
| Port thread 22 | M16 x 1.5 JED - 388 |
| Port thread 3 | JED-463-1 |
| Heating Connection | Bayonet DIN 72585-A1-2.1-1-Sn/K2 |
| Port thread 24 | M22 x 1.5 JED - 388 |
| Port thread 12 | M12 x 1.5 |
| Silencer | No (432 407 015 0 retrofittable) |
| Unloader | Yes |
| Port thread 21 | M22 x 1.5 |
| Port thread 23 | Tire inflation device M16 x 1.5 |
WABCO 9324000240 Cross Reference
We have 6 alternatives for the 9324000240 by WABCO:
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
