Name: FRAM TG12939 Cartridge Oil Filter
SKU: tg12939
Price: 55.99 USD
Availability: InStock

FRAM part description

Cartridge Oil Filter

Product Description

FRAM, TG12939, Oil Filter

Features & Benefits

Proven protection for up to 15,000 miles (24,000 kilometers)
Engineered for tough driving conditions, stop and go traffic, and hot and cold temperatures
Synthetic blend media provides 99% dirt holding capacity
Designed for use with synthetic or conventional motor oils
Includes gaskets and O-rings manufactured to endure the high pressures and high temperatures in today’s engines

Cartridge Oil Filter

Product Attributes

Anti-Drain Back Valve	No
Bypass Relief Valve	No
Filter Media Material	Cellulose/Synthetic Blend
Filter Type	Cartridge
Gasket Or Seal Included	Yes
Grade	Premium
Grade Type	Premium
Height	5.649 IN
Housing Color	NA
Inside Diameter Bottom	1.024 IN
Meets Or Exceeds Original Equipment Manufacturer Specifications	Yes
New Or Remanufactured	New
Non Slip Grip	No
O-ring (1) Inside Diameter	2.953 IN
O-ring (1) Outside Diameter	3.095 IN
O-ring (1) Thickness	0.142 IN
O-ring (2) Inside Diameter	0.362 IN
O-ring (2) Outside Diameter	0.466 IN
O-ring (2) Thickness	0.104 IN
O-ring (3) Inside Diameter	0.925 IN
O-ring (3) Outside Diameter	1.027 IN
O-ring (3) Thickness	0.102 IN
O-ring Inside Diameter	0.787 IN
O-ring Outside Diameter	0.891 IN
O-ring Thickness	0.104 IN
O-Rings Included	Yes
Outer Diameter Bottom	3.295 in
Outer Diameter Top	3.295 in
Replacable Filter	Yes
Reusable	No
Top Inside Diameter	Closed in
Torque Nut	Yes
Washable	No
Washer Indside Diameter	0.563 IN
Washer Outside Diameter	0.768 IN
Washer Thickness	0.059 IN

Additional Information

Warranty Special	See Rep
Warranty Special UOM	SR
Warranty Time	30
Warranty Time UOM	DA
Country of Origin (Primary)	CN
Harmonized Tariff Code (HTS)	8421230000
UPC	00840357607305
UNSPSC	15121501

Part Interchanges

Fits Vehicles

Jeep Gladiator (2021-2023)
Ram 1500 (2020-2023)
Jeep Wrangler (2020-2023)
Suzuki Aerio (2002)
