Name: NGK Spark Plugs 3722 NGK Standard Spark Plug
SKU: 3722
Price: 2.7 USD
Availability: InStock

NGK SPARK PLUGS part description

BR5HS S-PLUGS

Product Description

NGK Standard Spark Plug

Features & Benefits

ACTUAL OE or EQUIVALENT DESIGN: OEM quality construction nickel alloy center electrode provides consistent performance
RECOMMENDED USAGE: Best for vehicles with OE nickel alloy plugs, not recommended on vehicles with factory precious metal plugs
NGK's OE CERAMIC TECHNOLOGY: High grade alumina silicate ceramic creates a stronger insulator for optimal dielectric performance
SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
COLD-ROLLED THREADS: Prevents cross-threading and damage to cylinder heads
TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal

Product Attributes

Stock Number	3722
Part Number	BR5HS
Resistance	5000.0 82
Ground Electrode Tip Design	Standard
Ground Configuration	J-Gap
Ground Electrode Core Material	Nickel
Electrical Terminal Type	Removable Nut
Center Electrode Core Material	Copper
Center Electrode Tip Material	Nickel
Pre-Gap Size	.024 IN
Ground Electrode Quantity	1
Hex Size	13/16 IN
Insulator Height	55.00 MM
Manufacturer Heat Range	5
Seat Type	Flat
Reach	0.500 IN
Thread Diameter	14.00 MM
Short Style Spark Plug	No
Service Number	BR5HS
Washer Included	Yes
Grade Type	Regular
Hex Size	13/16"
Insulator Height	2.14 IN
Thread Diameter	0.551 IN
Insulator Material	Ceramic
Resistor Type	Yes
6648	0.0 IN
Ground Electrode Tip Material	Nickel
9459	No
9506	0.04 IN
9608	Standard
9745	Crush
9805	Non-Projected

Additional Information

Warranty Time UOM	MO
Warranty Time	2
Country of Origin (Primary)	JP
Harmonized Tariff Code (HTS)	8511100000
UPC	00087295137222
VMRS Code	033003005
UNSPSC	26101732

Part Interchanges

Fits Vehicles

John Deere Gator CX 4x2 (2010-2015)
Volkswagen Beetle (1950-1953)
Volkswagen Transporter (1950-1953, 1967-1972)
Chevrolet Corvair (1960-1969)
