(888) 312-8812 Login SignupDONALDSON P553771 Engine Oil Filter - 7.87 in., Full-Flow Type, Spin-On Style, Cellulose Media Type, with Bypass Valve
MSRP: $21.31
$1899
Save $2.32
Limited availability at this price!
In Stock
Get as soon as Tuesday, Oct 13
DONALDSON P553771 Part Description
Manufacturer
Product Description
LUBE FILTER, SPIN-ON FULL FLOW
Features & Benefits
- Cellulose spin-on media captures wear debris in normal full-flow oil service
- Seven-point-eight-seven-inch canister uses a 1-12 UN thread at the matching lube-filter head
- Maintains another oil path if full-flow filter restriction rises
- Adds fresh full-flow filtration at routine engine-oil service
Donaldson Engine Oil Filter
Keep abrasive wear debris from circulating repeatedly through loaded engine surfaces with the Donaldson Engine Oil Filter. Full-flow cellulose media in the Donaldson P553771 captures routine contamination during normal lubrication, while an internal bypass keeps another oil path available if cold oil or a loaded element becomes too restrictive. The bypass keeps filtration from becoming a reason for the engine to lose lubrication flow when restriction rises too far. A correct 1-12 UN connection and gasket seal keep normal oil moving through the media as intended.
DONALDSON P553771 Specifications
Product Attributes
| Anti-drainback Valve | Yes |
| Bypass Valve | Yes |
| Bypass Valve Setting Hr | 2.5 BAR |
| Bypass Valve Setting LR | 2 BAR |
| Collapse Burst | 6.9 BAR |
| Efficiency 99% | 40 MICRON |
| Gasket Id | 2.4 IN |
| Gasket Od | 2.8 IN |
| Length | 7.87 IN |
| Media Type | Cellulose |
| Outer Diameter | 3.66 IN |
| Style | Spin-On |
| Thread Size | 1-12 UN |
| Type | Full-Flow |
| Efficiency Test Std | ISO 4548-12 |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (HTS) | 8421230000 |
| UPC | 00742330044445 |
DONALDSON P553771 Cross References
| Brand | Part Number |
|---|---|
| ABG | 1160025 |
| AC DELCO | PF2154, X22 |
| AGCO | 1174421 |
| AHLMANN | 1160025, A15H4123 |
| ALLIS-CHALMERS | 61671160, 61671600, 61673585, 99100208 |
| BALDWIN | B236 |
| FLEETGUARD | LF4054, LF3413 |
| FRAM | PH3776 |
| LUBER-FINER | LFP2222 |
| MANN-HUMMEL FILTERS | W962 |
| N/A | LF315, HDO10, P7053, PH2801, PH2801A, PH2924, PH2968, PH3735, PH3776, PH4868, PH7718, L149, L40106, L47033, OC32, OC60, PC248, PC33, PER106, PER2168, PER319, 51772, 51820E, 51820, L05A565, 92772, 92818, 92820, B236, B7143, B9601, BT8433, B7367, 04701244, 69008950, 69024474, 4701244, 85772, 85820, LF3784, LF3687, LF3932, LF797, LFR8797, LFR84054, LFR83625, 1772, 1820, J8610962, 8931529, 8985117, 8985134, PF2154, X22, PL4017, 0814661, 1032977, 3I1361, 3I1999, 5W6017, 814661, 67008922, M8M60984, 5000859, 5010664, 552352604, 6106841, 82DF6714AA, 82DF714AA, A730X6714FA, A820X6714NA, BF9T6714AA, C77NF933A, TAC115561, 250521, OC20020, SFO4054, 5710640, 5821220, C4905, C6101, C6204, WGL797, WGL962, SFO0818, W11703, W96214, W96228, W96247, W9626O, W9628, 6750558336, 6750558476, 6750559016, 1174421, 1504034OW, 1504039OW, 4034OW, 220047, 116003, 13022760, 13022761, 8319000048, 1111602030900, 1160025, 000922604, 2871722M1, 2998553M1, 194932128, 22604, 5205401300, 711922604, 88000922604, 922604, F284201310040, F824201310040, H181W, H18W01, H18W03, H303W, 0024164103, 0024560060, 24164103, 24560060, 24564058, 24564060, 3564103, 500079078, 6005019741, 6005019757, 6005025477, 0011849601, 11849601, K0150521, K0850588, 150521, R1350575, V0850559, 01160025, 01173430, 01901919, 1173430, 1901919, 61671160, 61671600, 61673585, W962, 3BP20219, A44081, AZ22878, 1621183, 1621183M91, 2871722M2, 2998553, 2004287, 234486, 2344865018, 00234486, 05500874, 11781186, 24650040, 3136460R91, 43299200, 5500874, 901000, 5507547, 5502096, 550209603, 550209623, 5502029, A15H4123, 31P0103, 51055010003, 5105501002, 51055010002, V37624, 531005, 00073033, 0046826, 046826, 103909, 1409921, 73033, G0250522, 46826, H0575, 9724508667, 1627410121, 3216921400, 442004, 9121033800, 12028496, 1202849600, 1612398000, 16192627, 1619262700, 9721033800, 9709001200, 9712540104, 97125401204, 9712540404, 97210338, 16193771, 29000338, 2914812000, 321692140, 97090012, S869, 160000002001, 16000000201, 9830610, 0009830610, 0160000001001, 0160000002001, 160000001001, 15021, 3055270R91, 3059247R91, 3136406R91, 3136460A91, K0850888, P1350575, V36774, V3R624, 605411880008, 01183575, 03002261, 1162921, 3002261, Q15H4123, 01173430EE, 01174421, 01181749, 116004, 1162757, 1173430EE, 1181749, 1182552, 1183575, 150157520, 363020, 400651042, 846080160, 8701155447, D00053, 0499950339, 499950339, 668610050, 9237260080, SAK700, VPD5032, 40507408, 0040507408, 17535046, 1114786, 119935430, 11993545, 119935450, 1199354M, 17457469, 17535679, 3831236, 62114897, VOE17535679, VOE3831236, 1936, MU5074, MU5345, 4050740, 451105067, 451105182, 451105188, 9457280400, P5067, P5188, 451301001, 451105001, 0451104015, 0451105001, 0451105067, 0451301001, 451104015, 894123, EFL161, EFL222, FL761, 6LS1114, 2030, 2194, AZL032, 1839102, 1839106, 431035, 3032745R1, AP3193, AP3193A, AP3213, AP3213A, AP3221A, AP3553, LK3193, LK3213, 1153430, 1174576, 1174577, 2901501, 671160, 673588, 7211141300, 9128, 99100208, 1457012, 111888000, 1448080, BC1035, LS4798, LS479A, LS497B, LS712, LS712C, LS414, LS479, Z129, Z74, 928040, 92804017, 92811117, SO040, 4795837, 58832932, 306000206, 114786, 00681, 02250153935, 521500, 681, LF4054, 2250153935, 04355, 4057120, 4355, 486610, 229K, 2042, 2102, 2130, 304, 9325, LO823K, 159332, FO1088, FOE071, MD13661, T3144, SO3413, SO7262, SO797, 07114786, 7114786, 07247138, 7247138, C219, 502848, 38494886, 51056612, 17771734, 35330687, 38494829, 72221450, 85052751, 92118678, 92740950, 61000070005, 8104266, UL327, 21640514, 1010384, 15209T9008, 7971783, 41150057A, 4115057, FO3861, 52587875, 554505, OK57, 2310601, 11425814, OC171, HC97, 9414100529, 17221331206, 172213312062, SP427, 1000129597, 46080160, 5710634, 5717494, 05710634, 05710640, 0114786, 0671490, 240611049, 671490, 131323, 1470319, 4134217, 4134784, Y03722710, ABU8537, 2VC115561, 36014054, 40001350, 6, 619180, 619810, 6198100, 1173430E, MH365, MH365P, 98024725, 905411880008, GL579X, GL597X, 4631281100, 330560039, FE201, 161000070005, 6100705 |
| PREMIUM GUARD | HG50049 |
| PUROLATOR | L40106 |
| WIX FILTERS | 51820 |
DONALDSON P553771 Customer Reviews
No reviews yet
Be the first to review this product!
DONALDSON P553771 Manufacturer Information
For more than 100 years, Donaldson® has provided effective solutions to complex filtration challenges in various industries. Fleet managers worldwide have relied on Donaldson’s wide range of filtration products to ensure their trucks operate at peak efficiency and reduce expenses and maintenance downtime in the long run. These products include air intake filters and cleaners, cabin air filters, coolant filters, fuel filters and water separators, transmission filters, exhaust filtration products, and so much more. Each Donaldson filtration product is engineered for durability and performance that matches that of the original. Whether they are long-haul trucks, school buses, dump trucks, or other commercial vehicles, Donaldson filtration products will help keep them running smoothly.
DONALDSON P553771 Questions & Answers
No questions yet
Be the first to ask a question about this product!
