DONALDSON M100463 Exhaust Muffler - 51.00 in. Overall length

★★★★★ (1)
M100463 by DONALDSON - Exhaust Muffler - 51.00 in. Overall length
DONALDSON

MSRP: $378.16

$368.49

Save $9.67

Limited availability at this price!

In Stock

Get it by Friday, Jul 10
No Hassle Return Policy Details
Free Economy shipping on orders over $499 details

DONALDSON M100463 Part Description

Manufacturer

DONALDSON

Product Description

ON-ROAD APPLICATIONS

Features & Benefits

  • 51-inch overall length for optimal exhaust control and performance
  • Balances backpressure to maintain engine efficiency and power
  • Meticulously created to handle hazardous conditions without degradation
  • Guarantees smooth exhaust flow for peak operational performance
  • Extended 44.44-inch body length enhances noise reduction and airflow efficiency

Donaldson Exhaust Muffler

The Donaldson Exhaust Muffler doesn’t just quiet the noise—it refines it, shapes it, and makes sure the truck’s power is heard without sacrificing performance. Weak exhaust systems choke the engine, disrupting airflow and robbing the truck of its full potential. That’s not what this muffler is about. At 51 inches of controlled exhaust flow, it balances backpressure, optimizes efficiency, and keeps the truck performing at its peak without unnecessary strain. It’s built to survive extreme temperatures and harsh conditions, ensuring it doesn’t just hold up but continues to deliver superior performance in every journey. Choose the Donaldson M100463 today.

DONALDSON M100463 Specifications

Product Attributes

Body Length 44.44 in
Overall Length 51.00 in
Attenuation Hr 18 DBA
Attenuation Lr 13 DBA
Back Pressure High-range 2.99 INHG
Back Pressure Low-range 0.98 INHG
Back Pressure Mid-range 2.01 INHG
Body Diameter Maximum 10.06 IN
Inlet Diameter 5.03 IN
Outlet Diameter 5.03 IN
Rated Flow Hr 92.3 m³/min
Rated Flow Lr 66.2 m³/min
Rated Flow Mr 87.7 m³/min
Style Style 1
Overall Length 51 IN
Body Length 44.44 IN

Additional Information

Country of Origin (Primary) US
Harmonized Tariff Code (HTS) 8708925000
UPC 00742330005484

DONALDSON M100463 Cross References

BrandPart Number
A P PARTS3640, 3640Q
AP EXHAUST PRODUCTS INC3640
ASTEC UNDERGROUND22000214
BADGER520333, 76046685, 76072870
CATERPILLAR817066
N/A15251993, 27006340, 3640, LBP5510, 11165, 504808, 7642000054, 536969, 5369690, 5369790, 153612179, 3612179, D8HS5225EA, 049044343, 1114917, 1594513, 230010011, 230010047, 230013409, 230013417, 49039303, 49044343, 557686, V1114917, 2191MPM100463, 2ME236P1, 2ME248, 2ME29301P17, 2ME29301P18, 2ME29301P19, 2ME29301P20, 2ME49301P3, 2ME49301P5, M100127, M100338, 86130M, 230010008, 7642000024, 7642000041, 4002827000, P2980524292, 21090, 21093, 10000468, 523269968, 9575M100463, 9575MPM100463P, D7HT5225BEA, D7HT5230FYA, D8HS525EA, D8HZ5230AB, D8HZ5230AV, E1HS5230AA, 125675, 420V6308, 4124051, 22691640, 46651026, 46651050, A04117170, A04117171, A04122700, DNM100463, DNMPM100463, D45000307, MPM100463, 720190011, 230013455, 28A1475, 520333, 76046685, 76072870, 58167925, 1909898, 69427B, 9HB910, 10009862, 5430127348, 222434, 931190, 52892
NAVISTARFLT86130M
