Dana 90-4-501-1X - SPL90 Series Automatic Transmission Yoke - Steel, 34 Spline, BS Yoke Style
$29749
MSRP: $343.91
Save: $46.42
In stock
limited availability at this price!
. Learn more
DANA part description
Specifications
| Brand | Spicer |
| Series | SPL90 |
| Spline Count | 34 |
| Yoke Style | BS |
| Hub Diameter R | 2.562 |
| C/L To End Hub S | 5.625 |
| Type | Splined Hole |
| Outside Yoke Dimension (In) E | 5.375 |
| Yoke Bearing Dimension (In) D | 1.625 |
| Major Diameter | 1.790 |
| Involute Spline | Y |
| Length Thru Hole Q | 2.750 |
| VMRS | 026001083 |
| Includes Slinger/Plug | Y |
| Assembly | Y |
| Material | Steel |
| Package Type | EACH |
| Package Qty | 1 |
| Weight | 4.33 LB |
| Country of Origin | Mexico |
Product Description
Features & Benefits
- Dana manufactured Spicer components are designed, engineered, tested, and manufactured to meet or exceed OE requirements.
- Spicer components are engineered to meet or exceeds the performance requirements of the original factory driveline component
- Tested for unparalleled reliability
- Strength and durability for long life
Product Attributes
| Series | SPL90 |
| Material | Steel |
| Spline Count | 34 |
| Type | Splined Hole |
| Assembly | Y |
| Hub Diameter R | 2.562 IN |
| Includes Slinger/Plug | Y |
| Involute Spline | Y |
| Length Thru Hole Q | 2.750 IN |
| Outside Yoke Dimension (In) E | 5.375 IN |
| Yoke Bearing Dimension (In) D | 1.625 IN |
| Yoke Style | BS |
| Major Diameter | 1.790 IN |
| C/L To End Hub S | 5.625 IN |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8708990000 |
| Harmonized Tariff Code (HTS) | 8708990000 |
| UPC | 00023913248864 |
| VMRS Code | 026001083 |
Part Interchanges
- Daimler Truck North America 680 410 10 28
- Daimler Truck North America 9045011X
- Daimler Truck North America F5HS 7089 AA
- Daimler Truck North America SP 90 4 501 1X
- Daimler Truck North America SP 90 4 501 1XHP
- Dana Commercial Vehicle Service Parts 100-4-1021-1X
- Volvo SP 9045011X
- Hino 37304E0040
- Hino 37324-6520A
- Hino S3732-46520
- International Harvester (IHC) 3538335C91
- International Harvester (IHC) 9045011X
- International Harvester (IHC) D9045011X
- International Harvester (IHC) E9045011X
- Navistar 3538335C91
- Navistar 9045011X
- Navistar D9045011X
- Navistar DS9045011X
- Navistar E9045011X
- Paccar Parts 90-4-501-1X
- Workhorse W0008151
- Mack 2104-9045011X
- Freightliner 680 410 10 28
- Freightliner 9045011X
- Freightliner F5HS 7089 AA
- Freightliner SP 90 4 501 1X
- Freightliner SP 90 4 501 1XHP
- Kenworth 90-4-501-1X
- Blue Bird 00108884
- UAP 90-4-501-1X
DANA 90-4-501-1X Cross Reference
We have 2 alternatives for the 90-4-501-1X by DANA:
Dana Holding Corporation® is an internationally known company specializing in drivetrain and e-Propulsion systems. It conceptualizes, manufactures, and supplies energy-management and power- and conveyance solutions for the present-day and future vehicles and trucks. With its over 115 years of industry experience and innovation, and despite several turbulences the automotive and trucking industry has been through, Dana has managed to take the lead in revolutionary technological inventions. Dana Holding Corporation comprises different world-renowned brands catering to various market segments. These include SPICER Drivetrain Systems, VICTOR REINZ Sealing Products, LONG Thermal Products, BREVINI Motion Systems, GRAZIANO High-Performance Transmissions, FAIRFIELD Custom Gears and Drives, and a lot more.
