DANA part description

Specifications

FN *
D1 Bearing Cap Dia 1.938
D2 Bearing Cap Dia 1.938
OEM Mfg SPICER
OEM Series 1810
Greasable YyesNno Y
E1 Brg Plate Dim 7.547
E2 Brg Plate Dim 7.547

Dana Holding Corporation Spicer 1810 Series U-Joint

The Dana Holding Corporation Spicer 1810 Series u-joint is crafted from high-quality materials to deliver best-in-class efficiency and outstanding durability. A part of the vehicle’s driveline, this u-joint helps restore the vehicle’s superior ride and handling.

Features & Benefits

  • Manufactured to meet strict quality standards for guaranteed dependable performance
  • Helps make the vehicle or truck operate at peak performance levels
  • Spicer products are designed to the same exacting standards as specified by OEMs
  • Efficiently keeps grease in and contaminants out for maximum retention in various environments
Series 1810

Product Description

Features & Benefits

  • Kit includes new self locking bearing plate bolts and new strap kits
  • Journal cross is engineered with a solid cold-formed body to ensure better wear and overall strength
  • Bearing cups are heat treated for strength; precision-ground and case-hardened for durability
  • Multi-lip seal keeps grease in and contaminants out, and gets maximum retention in a wider range of environments
  • Thrust washers eliminate metal-to-metal contact, prevent wear and lower the overall operating temperature

Product Attributes

Bearing Cap Diameter (1) 1.938 IN
Bearing Plate (1) 7.547 IN
OEM Mfg Spicer
OEM Series 1810
Type HR Style
Bearing Cap Diameter (2) 1.938 IN
Grease Zerk Included Y
Grease Fitting Location Side of Cross
Greaseable Y
Bearing Cap Diameter A (mm) 49.225 MM
Bearing Cap Diameter B (mm) 49.225 MM
Bearing Cap Type A Bearing Plate
Bearing Cap Type B Round
Hardware Included Y
Length A (In) 7.547 IN
Length A (mm) 191.694 MM
Length B (In) 7.547 IN
Length B (mm) 191.694 MM
Mounting Hardware Included Y
Sr(2)brng Cap To Brng Cap(osr) 7.547
Material Steel
Distance Between Bolts (1) 2.437 IN
Distance Between Bolts (2) 2.437 IN
Bearing Cap Type Bearing Plate X Round

Additional Information

Country of Origin (Primary) MX
Harmonized Tariff Code (Schedule B) 8708996820
Harmonized Tariff Code (HTS) 8708996820
UPC 00023913121822
VMRS Code 024002046

Part Interchanges

DANA 5-676X Cross Reference

We have 6 alternatives for the 5-676X by DANA:

Dana Holding Corporation® is an internationally known company specializing in drivetrain and e-Propulsion systems. It conceptualizes, manufactures, and supplies energy-management and power- and conveyance solutions for the present-day and future vehicles and trucks. With its over 115 years of industry experience and innovation, and despite several turbulences the automotive and trucking industry has been through, Dana has managed to take the lead in revolutionary technological inventions. Dana Holding Corporation comprises different world-renowned brands catering to various market segments. These include SPICER Drivetrain Systems, VICTOR REINZ Sealing Products, LONG Thermal Products, BREVINI Motion Systems, GRAZIANO High-Performance Transmissions, FAIRFIELD Custom Gears and Drives, and a lot more.
