RAYBESTOS 8541 - Brake Parts Inc Raybestos Specialty - Truck Disc Brake Rotor
$15199
5 day lead time
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
RAYBESTOS part description
California Proposition 65 Warning
California Proposition 65 Warning
WARNING: This product can expose you to chemical which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov. (Read more)
Product Description
Raybestos Specialty - Truck Brake Rotor
Application Summary
2012-2006 Workhorse Custom Chassis W42 Rear, 2011-2006 Workhorse W42 Rear
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 4.65 IN |
| Center Hole Diameter | 118.1 MM |
| 9565 | Conventional |
| Discard Thickness | 1 IN |
| Discard Thickness | 25.4 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 7.183 IN |
| Inside Diameter | 182.45 MM |
| Mounting Bolt Hole Circle Diameter | 7.25 IN |
| Mounting Bolt Hole Circle Diameter | 184.15 MM |
| Mounting Bolt Hole Diameter | 0.687 IN |
| Mounting Bolt Hole Diameter | 17.45 MM |
| Mounting Bolt Hole Quantity | 10 |
| Nominal Thickness | 1.102 IN |
| Nominal Thickness | 28 MM |
| Outside Diameter | 11.8 IN |
| Outside Diameter | 299.7 MM |
| Overall Height | 6.043 IN |
| Overall Height | 153.5 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 10 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| UPC | 00829352766736 |
Part Interchanges
RAYBESTOS 8541 Cross Reference
We have 11 alternatives for the 8541 by RAYBESTOS:
Fits Vehicles
- Workhorse Custom Chassis W42 (2006-2012)
- Workhorse Custom Chassis W62 (2008)
- Workhorse W62 (2008)
- Workhorse W42 (2006-2011)
