WIX FILTERS part description

CABIN AIR FOREIGN

Product Description

WIX Cabin Air Panel

Cabin filter location # 3 Behind glove box (glove box must be removed) 1 – Open glove-box – remove the locking tabs on both sides of the glove –box 2 – Remove the three screws holding the compartment in place then close the glove-box. 3 – Remove the access panel directly under the glove-box. 4 – Remove the two screws under the access panel 5 – Remove the access panel under the radio – remove the screw on the right side under this panel. 6 – Remove the kick panel under the glove-box – there are two screws on the underside of the glove-box and one screw attached to the metal bar. Lift out the entire glove compartment – disconnect the wire on the left side. 7 – Remove the two remaining screws on both sides of the metal bar covering the cabin air filter cover. 8 – Open the cabin air cover from the bottom – remove the two filters and replace.

Product Attributes

Duty Type LD
Media Material Particulate
Height 1.181 IN
Width 3.779 IN
Length 11.575 IN
Inner Diameter Top Closed
Class D
Style Cabin Air Panel

Additional Information

Country of Origin (Primary) CN
Harmonized Tariff Code (HTS) 8421390115
UPC 00765809247529

Part Interchanges

Fits Vehicles

  • Honda Accord (1998-2002)
  • Acura TL (1999-2003)
  • Acura CL (2001-2003)

Since its establishment in 1939, the name WIX Filters® has been synonymous with a strong tradition of excellence. This brand opened its door to business in an old cotton mill in Gastonia to provide its customers with premium-quality filters that exceed their performance demands. Within 15 years since it was founded, WIX Filters have revolutionized the automotive filtration system by introducing and patenting the spin-on oil filter design called “twist of the wrist,” which quickly became the industry standard. The eight decades of growth and innovation made WIX Filters a global leader in filtration, with over 12,000 unique product numbers covering a wide range of fuel, oil, air, coolant, cabin air, and transmission filters for domestic and foreign vehicles and industrial applications and more than 8,000 part numbers for fluid power systems and hydraulic applications.
