RAYBESTOS 9951 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
Raybestos Specialty - Street Performance Brake Rotor
RAYBESTOS 9951 Specifications
Product Attributes
| Nominal Thickness | 0.865 IN |
| Outside Diameter | 9.565 IN |
| Overall Height | 1.79 IN |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 5 |
| Harmonize Code | 8708.30.5030 |
| Salability Restrictions | No |
| UNSPSC Code | 25171715 |
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.127 IN |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.827 IN |
| Mounting Bolt Hole Circle Diameter | 3.937 IN |
| Mounting Bolt Hole Diameter | 3.937 IN |
| Mounting Bolt Hole Quantity | 5 |
| Center Hole Diameter | 54.05 MM |
| Discard Thickness | 21 MM |
| Mounting Bolt Hole Circle Diameter | 100 MM |
| Mounting Bolt Hole Diameter | 100 MM |
| Nominal Thickness | 21.95 MM |
| Outside Diameter | 242.95 MM |
| Overall Height | 45.45 MM |
Additional Information
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00030999165114 |
RAYBESTOS 9951 Cross References
| Brand | Part Number |
|---|---|
| Advance Auto Parts | 141369, YH141369, YH141369C |
| American Remanufactured | 789-22022, 89-22022 |
| AutoZone | 3122, 3122DG |
| Autopart International | 78089 |
| Autospecialty | JBR181, JBR181E |
| Axxis | 085-6490, 085-6840 |
| Beck/Arnley | 080-2048, 083-2048 |
| Bendix | 141369, 145135 |
| Brake Headquarters | BR06162 |
| Brake Pro | 4619265 |
| BrakeBest | 9951, 9951R, 9951RGS, BD60706, 9954RGS |
| Brembo | 09.3022.10, 25215 |
| CENTRIC | 121.44023 |
| California Drum & Rotor | 60706 |
| Casting Numbers | 210377-C, 31221, 325043, 6877 |
| Centric Parts | 120.44023, 121.44023 |
| Century | 9265 |
| Dayton Walther | D7886 |
| Delphi | RB228 |
| Dura Corp | BR3122 |
| DuraGo | BR3122 |
| EIS Brakes | D9084 |
| Eurorotor | TO610 |
| GREN | 10602 |
| Girling | GR650 |
| Guardian | 52-60706 |
| Hollander | 58012 |
| ITM Engine Components | 1601517 |
| Interbrakes | TY171V |
| MCI | 4029 |
| Midas | BR1397 |
| Mighty Distributing System | 3122 |
| Monroe Brakes | BD60706 |
| Mountain Off-Road Enterprises | TR37 |
| Newtek Automotive USA | 3122 |
| PRONTO | BR3122 |
| Parts Master | P60706 |
| Qualis | 3122 |
| Qualitee International | 64-79-370 |
| Quality Brand | 3122 |
| Quinton Hazell | BDC3560 |
| Roadmates | 526565 |
| Rockhill | 3122 |
| Standard Rotors and Drums | 3122 |
| Toyota | 4351232020, 4351232040, 4351232110, 4351232140 |
| TruStar | 479370, R79370 |
| UAP | 3122 |
| Universal | 107220 |
| VIPAR - Vehicle Indusrty Parts & Manufacturing | X50374 |
| Vera | 3403091 |
| WAGNER | BD60706 |
| Wagner Brake | BD60706 |
| Winhere | YH2053 |
