RAYBESTOS 96030 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
Raybestos Specialty - Street Performance Brake Rotor
RAYBESTOS 96030 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.526 IN |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.748 IN |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Diameter | 0.504 IN |
| Mounting Bolt Hole Quantity | 4 |
| Nominal Thickness | 0.825 IN |
| Outside Diameter | 11.09 IN |
| Overall Height | 2.01 IN |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 4 |
| Harmonize Code | 8708.30.5030 |
| Salability Restrictions | No |
| UNSPSC Code | 25171715 |
| Center Hole Diameter | 64.15 MM |
| Discard Thickness | 19 MM |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 12.8 MM |
| Nominal Thickness | 20.95 MM |
| Outside Diameter | 281.7 MM |
| Overall Height | 51.05 MM |
Additional Information
| Country of Origin (Primary) | CA |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00030999233820 |
RAYBESTOS 96030 Cross References
| Brand | Part Number |
|---|---|
| Advance Auto Parts | 141528, YH141528, YH141528C, YH141548 |
| American Remanufactured | 789-08021, 89-08021 |
| AutoZone | 3184, 3184B, 3184DG |
| Autopart International | 78514 |
| Autospecialty | JBR521, JBR521E |
| BREMBO | 09525110 |
| Beck/Arnley | 080-2206, 083-2206 |
| Bendix | 141528 |
| Brake Headquarters | BR02016 |
| Brake Pro | 4618587 |
| BrakeBest | 96030, 96030R, 96030RGS, BD61799 |
| Brembo | 09.5251.10, 25312 |
| CENTRIC | 121.40020 |
| California Drum & Rotor | 61799 |
| Casting Numbers | 210602-C, 31841, 325356, 5164 |
| Centric Parts | 120.40020, 121.40020, 126.40020SL, 126.40020SR, 127.40020L, 127.40020R |
| Century | 9343 |
| Continental-ContiTech | CW21701 |
| Dayton Walther | D7985 |
| Delphi | RB191 |
| Dura Corp | BR3184 |
| DuraGo | BR3184 |
| EIS Brakes | D17276, D9077 |
| GREN | 43602 |
| Girling | GR814 |
| Guardian | 52-61799 |
| Honda | 45251SG0J00 |
| ITM Engine Components | 1601005 |
| Interbrakes | HO381V |
| MCI | 3806, 3945, 3945Q |
| Midas | BR1549 |
| Mighty Distributing System | 3184 |
| Monroe Brakes | BD61799 |
| Newtek Automotive USA | 3184 |
| PRONTO | BR3184 |
| Parts Master | P61799 |
| Qualis | 3184 |
| Qualitee International | 64-71-050 |
| Quality Brand | 3184 |
| Quinton Hazell | BDC4313 |
| Roadmates | 526604 |
| Rockhill | 3184 |
| Standard Rotors and Drums | 3184 |
| TruStar | 471050, R71050 |
| UAP | 3184 |
| Universal | 115840 |
| VIPAR - Vehicle Indusrty Parts & Manufacturing | X50458 |
| Vera | 3404213 |
| WAGNER | BD61799 |
| Wagner Brake | BD61799 |
| Winhere | YH2099 |
