FRAM CH6102 Part Description
FRAM CH6102 Specifications
Product Attributes
| Filter Media Material | Cellulose/Synthetic Blend |
| Height | 1.860 IN |
| Grade Type | Regular |
| Filter Type | Cartridge |
| Non Slip Grip | No |
| Anti-Drain Back Valve | No |
| Bypass Relief Valve | Yes |
| Bypass Relief Valve Setting | 11.4-17.1 PS |
| Grade | Advanced |
| Housing Color | NA |
| Inside Diameter Bottom | 0.315 IN |
| Meets Or Exceeds Original Equipment Manufacturer Specifications | Yes |
| New Or Remanufactured | New |
| O-ring (1) Inside Diameter | 2.088 IN |
| O-ring (1) Outside Diameter | 2.226 IN |
| O-ring (1) Thickness | 0.138 IN |
| O-ring (2) Inside Diameter | 1.970 IN |
| O-ring (2) Outside Diameter | 2.069 IN |
| O-ring (2) Thickness | 0.099 IN |
| O-ring (3) Inside Diameter | 0.264 IN |
| O-ring (3) Outside Diameter | 0.362 IN |
| O-ring (3) Thickness | 0.099 IN |
| O-ring Inside Diameter | 2.128 IN |
| O-ring Outside Diameter | 2.226 IN |
| O-ring Thickness | 1.970 IN |
| O-Rings Included | Yes |
| Outer Diameter Bottom | 1.489 in |
| Outer Diameter Top | 1.489 in |
| Replacable Filter | Yes |
| Reusable | No |
| Top Inside Diameter | 0.493 in |
| Torque Nut | No |
| Washable | No |
| Bottom Inside Diameter | 0.315 IN |
| Outside Diameter Top | 1.489 in |
| Replaceable Filter | Yes |
Additional Information
| Country of Origin (Primary) | IN |
| Harmonized Tariff Code (HTS) | 8421230000 |
| Warranty Special | See Rep |
| Warranty Special UOM | SR |
| Warranty Time | 30 |
| Warranty Time UOM | DA |
| UPC | 00009100539922 |
| UNSPSC | 15121501 |
FRAM CH6102 Cross References
| Brand | Part Number |
|---|---|
| BALDWIN | P40130 |
| CARQUEST | 84935 |
| Filtrex | OIF021 |
| HiFlo | HF142 |
| K & N | KN-142 |
| K&N | KN-142 |
| MANN-HUMMEL FILTERS | ML16852 |
| PUROLATOR | ML16852 |
| Sudco | 631-7142 |
| Vesrah | SF-2005 |
| WIX | 57935 |
| WIX FILTERS | 57935 |
| YAMAHA | 1UY-13440-00, 1UY-13440-02, 1UY13-44002, 1UY-13440-02-00 |
